5016B
5017B
5018B
5019B
* - See sensor manual for more details.
148
Frequency Range 350 MHz - 4.0 GHz
Power Range 25 mW - 25 Watts Avg. 60 Watts Peak
Measurements performed: Peak power, true average
power and Duty Cycle.
Calculations Performed: VSWR, Return Loss,
Reflection Coefficient, Crest Factor, Average Burst
Power and CCDF.
Duty Cycle (D) .001 to 1.0
Accuracy Average Power = ±4% of reading, + 0.008 Watts
Burst Average Power = ±6% of reading, +0.008/D Watts
Peak Envelope Power = ±7% of reading, +0.05 Watts
CCDF = ±0.2% typical
Frequency Range 25 MHz - 1.0 GHz
Power Range 500 mW - 500 Watts Avg. 1300 Watts Peak
Measurements performed: Peak power, true average
power and Duty Cycle.
Calculations Performed: VSWR, Return Loss,
Reflection Coefficient, Crest Factor, Average Burst
Power and CCDF.
Duty Cycle (D) .001 to 1.0
Accuracy Average Power = ±4% of reading, + 0.17 Watts
Burst Average Power = ±6% of reading, +0.17/D Watts
Peak Envelope Power = ±7% of reading, +0.70 Watts
CCDF = ±0.2% typical
Frequency Range 150 MHz - 4.0 GHz
Power Range 100 mW - 25 Watts Avg. 60 Watts Peak
Measurements performed: Peak power, true average
power and Duty Cycle.
Calculations Performed: VSWR, Return Loss,
Reflection Coefficient, Crest Factor, Average Burst
Power and CCDF.
Duty Cycle (D) .001 to 1.0
Accuracy Average Power = ±4% of reading, + 0.008 Watts
Burst Average Power = ±6% of reading, +0.008/D Watts
Peak Envelope Power = ±7% of reading, +0.05 Watts
CCDF = ±0.2% typical
Frequency Range 25 MHz -1.0 GHz
Power Range 100 mW - 100 Watts Avg. 260 Watts Peak
Measurements performed: Peak power, true
average power and Duty Cycle.
Calculations Performed: VSWR, Return Loss,
Reflection Coefficient, Crest Factor, Average Burst
Power and CCDF.
Duty Cycle (D) .001 to 1.0
Accuracy Average Power = ±4% of reading, + 0.04 Watts
Burst Average Power = ±6% of reading, +0.04/D Watts
Peak Envelope Power = ±7% of reading, +0.13 Watts
CCDF = ±0.2% typical
