BIRD BirdTechnologies SignalHawk SH-36S Operating Instructions Manual page 33

Figure 7 SignalHawk Start Menu - Vector Network Analyzer
Item
1 Name of measurement being used
2 Soft keys
3 Power source icon (AC, battery, or battery charging)
4 Go to the Help menu. See "Help Menu Key" on page 10.
5 Go to the Utilities menu. See "Utilities" on page 125.
6 Measurement mode lists
7 Menu keys
8 Selected measurement (highlighted)
9 Name and brief description of highlighted measurement
10 Current active operating mode
Description
11
