Examples and tips
/i
Input signal
P_OT (active high)
N_OT (active high)
DEC (active low)
EXT1 (active low)
EXT2 (active low)
EXT3 (active low)
E-STP (active high)
SI0 (active high)
SI1 (active high)
SI2 (active high)
PCL (active high)
NCL (active high)
For the Accurax G5 Servo Drivers, the CN1 input pins IN1 to IN8 can be
allocated to a specific function. To do this, you must set the appropriate
parameter of the Servo Driver. The table below shows the parameters to
allocate a function to a CN1 input pin.
/i
Parameter Parameter name
number
Pn400 Input Signal Selection 1
Pn401 Input Signal Selection 2
Pn402 Input Signal Selection 3
Pn403 Input Signal Selection 4
Pn404 Input Signal Selection 5
Pn405 Input Signal Selection 6
Pn406 Input Signal Selection 7
Pn407 Input Signal Selection 8
PROGRAMMING MANUAL
CN1 pin number
19
20
21
5
4
3
2
22
23
6
7
8
Description
Set the IN1 input function allocation
Set the IN2 input function allocation
Set the IN3 input function allocation
Set the IN4 input function allocation
Set the IN5 input function allocation
Set the IN6 input function allocation
Set the IN7 input function allocation
Set the IN8 input function allocation
