NOTE
In the Settings application, the Battery Test option allows you to change the requirement
for entering the VIN information. If the setting is enabled, supplying the VIN is no longer
mandatory.
Please refer to the table below for a list of buttons that may appear when accessing the
functions:
Button Name
Battery
Connection
Next
Home
Back
Exit
6.2.2 Battery Test
1. Follow the on-screen instructions. Check the boxes once all required tasks are
completed, and tap Start Testing.
2. Wait until the test is completed. The test results will be displayed on the tablet.
Table 6-1 Top Toolbar Buttons
Description
The value on the icon indicates the real-time voltage of
the tested battery. In the battery test, the button will turn
green if the battery is good; otherwise, it will turn red.
Tap to proceed.
Returns to the MaxiSys Job Menu.
Returns to the previous screen.
Returns to the Job Menu.
Figure 6-3 Battery Test Screen
64
