Button
Name
Camera
Display
& Sound
VCI
MaxiSys
Shortcut
Service
Shortcut

To use the camera
1. Tap the Camera icon. The camera screen opens.
2. Focus the image to be captured in the viewfinder.
3. Tap the camera icon on the right side of the screen. The viewfinder now shows
the captured picture and auto-saves the taken photo.
4. Swipe the screen left to view the stored photos.
5. Tap the Back or Home button to exit the camera application.
NOTE
After swiping the camera screen from left to right, the camera mode and video mode can
be switched by tapping the blue camera icon or video icon.
3.1.3 System Status Icons
Your MaxiSys tablet is a fully functional Android tablet with the standard Android
operation system status icons. Refer to Android documentation for additional information.

3.2 Power Down

All vehicle communications should be terminated before shutting down the tablet. A
warning message displays if a shutdown is attempted while the tablet is communicating
with the vehicle. Forcing a shutdown while the tablet is communicating with the vehicle
Description
Launches the camera. Press and hold to capture a
screenshot of the current screen. Saved files are stored in
the Data Manager application for later review. See
Manager.
Adjusts the brightness of the screen and the volume of the
audio output.
Opens the VCI Manager application. A green badge with a
BT or USB icon at the bottom-right corner indicates the VCI
is connected, while a red "x" icon will be displayed if the
connection fails.
Returns to the Diagnostics screen.
Returns to the Service screen.
15
Data
