Trademarks
®
Autel
,
MaxiSys
®
MaxiCheck
are trademarks of Autel Intelligent Technology Corp., Ltd., registered in
China, the United States, and other countries. All other marks are trademarks or
registered trademarks of their respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or transmitted in
any form or by any means electronic, mechanical, photocopying, recording, or otherwise
without the prior written permission of Autel.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on the latest
information available at the time of printing.
Autel reserves the right to make changes at any time without notice. While information
of this manual has been carefully checked for accuracy, no guarantee is given for the
completeness and correctness of the contents, including but not limited to the product
specifications, functions, and illustrations.
Autel will not be liable for any direct, special, incidental, or indirect damages, or for any
economic consequential damages (including the loss of profits) as a result of using this
product.
IMPORTANT
Before operating or maintaining this unit, please read this manual carefully, paying extra
attention to the safety warnings and precautions.
For Services and Support
pro.autel.com
www.autel.com
1-833-686-1349 (North America)
0086-755-86147779 (China)
support@autel.com
For technical assistance in all other markets, please contact your local Autel selling agent.
®
®
,
MaxiDAS
,
®
MaxiScan
,
MaxiTPMS
i
®
,
MaxiRecorder
®
,
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MaxiSys MS908CV II and is the answer not in the manual?

Questions and answers

Related Manuals for Autel MaxiSys MS908CV II

Summary of Contents for Autel MaxiSys MS908CV II

  • Page 1 Autel will not be liable for any direct, special, incidental, or indirect damages, or for any economic consequential damages (including the loss of profits) as a result of using this product.
  • Page 2 The safety messages herein cover situations Autel is aware of at the time of publication. Autel cannot know, evaluate or advise you as to all of the possible hazards. You must be certain that any condition or service procedure encountered does not jeopardize your...
  • Page 3 DANGER When an engine is operating, keep the service area WELL VENTILATED or attach a building exhaust removal system to the engine exhaust system. Engines produce carbon monoxide, an odorless, poisonous gas that causes slower reaction time and can lead to serious personal injury or loss of life.

  • Page 4: Table Of Contents

    CONTENTS 1 USING THIS MANUAL ....................1 ....................1 ONVENTIONS 1.1.1 Bold Text ...................... 1 1.1.2 Notes and Important Messages ..............1 1.1.3 Hyperlinks ..................... 1 1.1.4 Illustrations ....................1 1.1.5 Procedures ....................2 2 GENERAL INTRODUCTION ..................3 ................ 3 MS908CV II T ABLET 2.1.1...
  • Page 5 3.1.3 System Status Icons ................... 16 ....................16 OWER 3.2.1 Reboot System ................... 16 4 DIAGNOSTICS ......................17 ....... 17 STABLISH EHICLE OMMUNICATION AND ELECTION 4.1.1 Establish Vehicle Communication .............. 17 ..................21 ETTING TARTED 4.2.1 Vehicle Menu Layout .................. 21 ................
  • Page 6 4.8.2 Function Descriptions ................. 51 ..................53 IAGNOSTIC EPORT 4.9.1 Pre-Scan and Post-Scan Functions ............53 4.9.2 Diagnostics Report Saving, Viewing, and Sharing ........54 4.10 ..................59 IAGNOSTICS 5 SERVICE ........................60 ..................60 ESET ERVICE ..........61 (EPB) S LECTRIC ARKING RAKE...
  • Page 7 7 SETTINGS ........................73 ........................ 73 ...................... 73 ANGUAGE ..................... 74 RINT ETTINGS 7.3.1 Printing Operations ..................74 ....................75 EPORT ..................75 OTIFICATIONS ....................76 PDATE ....................76 EHICLE ..................77 YSTEM ETTINGS ......................77 BOUT 8 VCI MANAGER ......................78 ................
  • Page 8 ......................84 RAINING ..................84 PERATION ANUAL ....................84 OGGING FAQ ........................ 85 10 REMOTE DESKTOP ....................86 ....................86 10.1 PERATIONS 11 UPDATE ........................88 12 QUICK LINK ......................... 90 13 USER FEEDBACK ....................... 91 14 MAXIVIEWER ....................... 92 15 MAXIVIDEO ........................
  • Page 9 18 AUTEL USER CENTER ..................... 107 19 MAINTENANCE AND SERVICE ................108 19.1 ..............108 AINTENANCE NSTRUCTIONS 19.2 ..............109 ROUBLESHOOTING HECKLIST ................109 19.3 BOUT ATTERY SAGE ................110 19.4 ERVICE ROCEDURES 19.4.1 Technical Support ..................110 19.4.2 Repair Service ..................112 19.4.3 Other Services ..................

  • Page 10: Using This Manual

    Using This Manual This manual contains device usage instructions. Some illustrations shown in this manual may contain modules and optional equipment that are not included in your system. 1.1 Conventions The following conventions are used: 1.1.1 Bold Text Bold text is used to highlight selectable items such as buttons and menu options. Example: ⚫...

  • Page 11: Procedures

    option selection. 1.1.5 Procedures An arrow icon indicates a procedure. Example: ➢ To use the camera Tap the Camera icon. The camera screen opens. Focus the image to be captured in the viewfinder. Tap the Camera icon on the right side of the screen. The viewfinder now shows the captured picture and auto-saves the taken photo.

  • Page 12: General Introduction

    General Introduction The MaxiSys MS908CV II is an evolutionary smart solution for specialized automotive diagnosis. Utilizing the powerful octa-core processor (2.2 GHz quad-core A73 + 1.8 GHz quad-core A53) and a 9.7-inch LED capacitive touch screen, combined with the best...
  • Page 13 9.7” LED Capacitive Touchscreen Ambient Light Sensor — detects ambient light brightness. Microphone Figure 2-2 Tablet Top View DC Power Supply Input Port HDMI (High-Definition Multimedia Interface) Port USB Port USB Port Power/Lock Button — turns the device on/off with long press, or locks the screen with short press.

  • Page 14: Power Sources

    12. Camera Flash 13. Mini SD Card Slot 14. Mini USB Port 15. Headphone Jack 2.1.2 Power Sources The tablet can receive power from any of the following sources: ⚫ Internal Battery Pack ⚫ AC/DC Power Supply ⚫ Vehicle Power IMPORTANT Do not charge the battery when the temperature is lower than 0 °C (32 °F) or higher than 45 °C (113 °F).
  • Page 15 Item Description Memory 4 GB RAM & 128 GB on-board memory 9.7-inch LED capacitive touchscreen with 2048 x Display 1536 resolution Wi-Fi (802.11 a/b/g/n/ac) ⚫ USB 2.0 ⚫ Connectivity Bluetooth v5.0 + EDR ⚫ SD card (support up to 64 GB) ⚫...

  • Page 16: Maxiflash Elite - J2534 Ecu Programming Device

    Item Description ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, CAN ISO 11898, High-speed, Middle-speed, Low- Protocols speed and Singlewire CAN, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP 2.0, TP 1.6, SAE J1939, SAE J1708, Fault-Tolerant CAN 2.2 MaxiFlash Elite –...

  • Page 17: Power Sources

    Illuminates solid blue when the device is properly connected with the tablet via ⚫ Bluetooth connection. Power LED Illuminates solid green when the device is powered on. ⚫ Flashes red when a system failure occurs. ⚫ Illuminates amber automatically at power-up when the device is performing a ⚫...

  • Page 18: Technical Specifications

    2.3 Accessories Kit 2.3.1 Main Cable The MaxiFlash Elite device can be powered through the Autel main cable when connected to an OBDII/EOBD compliant vehicle. The main cable connects the MaxiFlash Elite device to the vehicle’s DLC, through which the MaxiFlash Elite device can transmit vehicle data to the tablet.

  • Page 19: Obdi-Type Adapters

    NOTE The MaxiFlash Elite device can be connected by the Autel main cable only. Do NOT use other cables to connect the MaxiFlash Elite device. 2.3.2 OBDI-Type Adapters The OBDI-type adapters are for non-OBDII vehicles. The adapter used depends on the type of vehicle being tested.
  • Page 20 AC/DC External Power Adapter Connects the tablet to the external DC power port for power supply. Auxiliary Power Outlet Adapter Provides power to the tablet or the MaxiSys Elite device through connection to the vehicle’s auxiliary power outlet adapter receptacle, as some non-OBDII vehicles cannot provide power via the DLC connection.

  • Page 21: Getting Started

    Getting Started Make sure that the tablet has sufficient power or is connected to the external power supply. (See Power Sources on page 8.) 3.1 Power Up Long press (press and hold) the Power/Lock button on the top-right side of the tablet to switch the unit on.

  • Page 22: Application Buttons

    See Settings on page 73. Accesses VCI connection menu. See VCI Manager VCI Manager on page 78. Synchronizes Autel’s online service database with Support the MaxiSys tablet. See Support on page 82. Configures your tablet to receive remote support Remote using the TeamViewer application.

  • Page 23: Locator And Navigation Buttons

    Accesses the Battery Test menu with two functions, Battery Test including in-vehicle test and out-vehicle test. See Battery Test on page 95. Allows users to register Autel tool for downloading the Autel User latest released software. See Autel User Center Center page 107.
  • Page 24 Icon Name Description Back Returns to the previous screen. MaxiSys Returns to MaxiSys Job Menu. Home Android Returns to Android system home screen. Home Displays a list of applications that are currently running. Tap an application icon to launch the Recent Apps application.

  • Page 25: System Status Icons

    ➢ To use the camera Tap the Camera icon. The camera screen opens. Focus the image to be captured in the viewfinder. Tap the Camera icon on the right side of the screen. The viewfinder now shows the captured picture and auto-saves the taken photo. Tap the thumbnail image on the top-right corner of the screen to view the stored images.

  • Page 26: Diagnostics

    4.1 Establish Vehicle Communication and Selection 4.1.1 Establish Vehicle Communication The Diagnostics operations require connecting the MaxiSys MS908CV II tablet to the test vehicle through the VCI device using the main cable. (Use the applicable OBDI-type adapter if needed.) To establish a proper vehicle communication to the tablet, you need to perform the following steps: Connect the VCI device to the vehicle’s DLC for both communication and power...
  • Page 27 OBDII Vehicle Connection This type of connection only requires the main cable without any additional adapter. ➢ To connect to an OBDII vehicle Connect the main cable’s female adapter to the Vehicle Data Connector on the VCI device, and tighten the captive screws. Connect the cable’s 16-pin male adapter to the vehicle’s DLC, which is generally located under the vehicle dashboard.
  • Page 28 After the VCI device is properly connected to the vehicle, the Power LED on the VCI device lights solid green, and is ready to establish communication with the tablet. Coming with the MaxiSys MS908CV II tool kit, the VCI device supports two communication methods with the tablet, Bluetooth and USB cable.
  • Page 29 ➢ To pair the tablet with the VCI device via Bluetooth Power up the tablet. Select the VCI Manager application from the MaxiSys Job Menu. When the VCI Manager application is opened, select VCI BT from the connection mode list and swipe the Bluetooth toggle button to ON. The device will automatically scan for available VCI devices for Bluetooth pairing.

  • Page 30: Getting Started

    4.1.1.3 No Communication Message A. If the tablet is unable to connect to the VCI, an “Error” message displays. An “Error” message indicates the tablet is not communicating with the VCI device, Troubleshoot the error by performing the following steps: Ensure the VCI device is powered on.
  • Page 31 Figure 4-2 Vehicle Menu Screen Top Toolbar Buttons Navigation Bar Manufacturer Buttons 4.2.1.1 Top Toolbar Buttons The operations of the toolbar buttons at the top of the screen are listed and described in the table below. Table 4-1 Top Toolbar Buttons Name Button Description...

  • Page 32: Vehicle Identification

    Name Button Description Displays the vehicle menu based on the selection Vehicle of the commercial vehicle type. Displays the vehicle menu based on the selection System of the vehicle system. Tap inside the search field to display a virtual Search keyboard and input the vehicle manufacturer to test.
  • Page 33 4.3.1.1 Auto VIN Scan The MaxiSys diagnostic system features the latest VIN-based Auto VIN scan function to identify CAN vehicles with just one tap, enabling the technician to quickly identify the exact vehicle and scan its available systems for fault codes. ➢...
  • Page 34 Figure 4-4 Diagnostics Main Menu Screen 4.3.1.2 Manual Input For vehicles that do not support the Auto VIN Scan function, the MaxiSys diagnostic system allows you to enter the vehicle VIN or license number manually, or simply take a photo of the VIN sticker or license plate for quick vehicle identification. ➢...
  • Page 35 Figure 4-5 Manual VIN Input Tap OK. The vehicle will be identified and matched to the vehicle database, and the system will guide you to the Vehicle Diagnostics screen. 4.3.1.3 Scan VIN/License Tap Scan VIN/License in the dropdown list (see Figure 4-3 VID Screen).
  • Page 36 Figure 4-6 Scan VIN Code 1 If the VIN/License number cannot be scanned, please manually input the VIN/License number. Tap OK to continue. Figure 4-7 Scan VIN Code 2 4.3.1.4 Manual Vehicle Selection When the vehicle’s VIN is not automatically retrievable through the vehicle’s ECU, or the specific VIN is unknown, you can select the vehicle manually.

  • Page 37: Navigation

    Step-by-step Vehicle Selection This mode of vehicle selection is menu-driven. Select a vehicle manufacturer on the Vehicle Menu screen and the Select Diagnostic Type screen displays, then tap the Manual Selection button. Select the vehicle information like the Brand, Model, Capacity, Engine type, and Model year on the same screen.
  • Page 38 Figure 4-9 Main Menu Screen Diagnostics Toolbar Current Directory Path Status Information Bar Main Section Function Buttons 4.4.1.1 Diagnostics Toolbar The Diagnostics Toolbar contains buttons that allow you to print or save the displayed data and perform other operations. The table below provides a brief description for the operations of the Diagnostics Toolbar buttons.
  • Page 39 This function will record communication data Data information of the test vehicle and send it to Autel’s Logging technical staff to review and provide solution. Go to the Support application to follow up the processing progress. See Data Logging on page 84.
  • Page 40 NOTE Make sure the tablet and the printer are connected either by Wi-Fi or LAN before printing. For more instructions on printing, see Print Settings on page 74 for details. ➢ To submit Data Logging reports in Diagnostics Tap the Diagnostics application button from the MaxiSys Job Menu. The Data Logging button on the Diagnostic Toolbar is available throughout the whole Diagnostics operations.

  • Page 41: Screen Messages

    4.4.2 Screen Messages Messages display when additional input is needed before proceeding. There are mainly three main types of on-screen messages: Confirmation, Warning, and Error. 4.4.2.1 Confirmation Messages This type of messages usually displays as an “Information” screen, when you are about to perform an action that cannot be reversed or when an action has been initiated and your confirmation is needed to continue.
  • Page 42 Figure 4-10 Auto Scan Operation Screen Navigation Bar ⚫ List Tab – displays the scanned data in list format ⚫ Progress Bar – indicates the test progress Main Section Column 1 — displays the system numbers ⚫ ⚫ Column 2 — displays the scanned systems ⚫...
  • Page 43 Table 4-3 Function Buttons in Auto Scan Screen Name Description Report Displays the diagnostic data in report form. Quick Erase Erases all fault information after scanning. Fault Scan Scans vehicle system modules. Pause Pauses the scanning process. Enter System Enters the ECU system. Returns to the previous screen or exits Diagnostics screen.
  • Page 44 Figure 4-11 Diagnostics Function Screen Available functions may vary by vehicle. The function menu may include: ECU Information — displays detailed ECU information. Select to display ⚫ information screen. Trouble Codes — contains Read Codes and Erase Codes. The former displays ⚫...

  • Page 45: Ecu Information

    4.6.1 ECU Information This function retrieves and displays the specific information for the tested control unit, including unit type, version numbers, and other information. Figure 4-12 ECU Information Screen Diagnostics Toolbar Buttons — see Table 4-2 Diagnostics Toolbar Buttons on page 29 for detailed descriptions of the operations of each button.
  • Page 46 Figure 4-13 Trouble Codes Screen Diagnostics Toolbar — see Table 4-2 Diagnostics Toolbar Buttons on page 29 for detailed descriptions of the operations of each button. Main Section ⚫ Column 1 — displays the retrieved codes from the vehicle Column 2 — indicates the status of the retrieved codes ⚫...

  • Page 47: Live Data

    ➢ To erase codes Tap Erase Codes in the Function Buttons. A warning message displays to inform you of data loss when this function is applied.  Tap Yes to continue. A confirming screen displays when the operation is successfully done. ...
  • Page 48 Diagnostics Toolbar Buttons – see Table 4-2 Diagnostics Toolbar Buttons on page 29 for detailed descriptions of the operations of each button. Main Section Name Column — displays the parameter names. ⚫  Check Box — tap the check box to the left of a parameter to select the item. Tap the check box again to deselect it.
  • Page 49 Figure 4-15 Display Mode Screen Each parameter item displays the selected mode independently.  Analog Gauge Mode — displays the parameters in gauge charts.  Text Mode — the default mode that displays the parameters as a text list. NOTE Status parameters, such as a switch reading like ON, OFF, ACTIVE, and ABORT can only be displayed in Text Mode.
  • Page 50 In this mode, five control buttons will display on the right side of the parameter, allowing you to manipulate the display status. Settings Button (SetY) — sets the minimum and maximum value of the Y-axis. Scale Button — changes the scale values. There are two scale buttons, displayed above the waveform graph to the right side, which can be used to change the scale values of the X-axis and Y-axis of the graph.
  • Page 51 Figure 4-17 Waveform Edit Screen The parameter item is selected automatically in the left column. Select a color from the second column. Select a line thickness from the right column. Tap Done to save the setting and exit, or tap Cancel to exit without saving. NOTE In full screen display, please edit the waveform color and line thickness by tapping the Edit button on the top right side of the screen.
  • Page 52 Figure 4-18 Trigger Setting Screen Two buttons and two input boxes are available in the Trigger Settings window. Trigger — switches the trigger on and off. The trigger is ON by default. Buzzer alarm — switches the alarm on and off. The alarm function makes a beep sound as an alert when the data reading reaches the preset minimum or maximum point.
  • Page 53 NOTE When the trigger is successfully set, a trigger mark displays in front of the parameter name. The mark is gray when it is not triggered, and displays orange when triggered. Moreover, two horizontal lines display on each of the data graphs (when Waveform Graph Mode is applied) to indicate the alarm point.
  • Page 54 ➢ To set live data record duration Tap the Setting button at the bottom of the Live Data screen. Tap the > button to the right of Recording time after trigger bar and select a time length. Tap OK to save the setting and return to the Live Data Setting screen; or tap the “X”...

  • Page 55: Active Test

    Show Selected — displays the selected parameters. ⚫ Graph Merge — merges selected data graphs. ⚫ Back — exits the review and returns to the Live Data screen. ⚫  Back — returns to the previous screen or exits the function. 4.6.4 Active Test The Active Test function is used to access vehicle-specific subsystem and component tests.

  • Page 56: Special Functions

    4.6.5 Special Functions Depending on the test vehicle, this selection may sometimes appear as Learning process, Correction programming, Emissions inspection (Not valid for USA), OBD I/M Check (Not valid for USA), or something similar. You can select one to proceed according to your demands.

  • Page 57: Coding

    NOTE Ensure that the tablet is connected to a stable internet access before applying the ECU programming function, so that the tablet is able to obtain access to the vehicle manufacturer's server for update service. Selecting the Programming opens a menu of operation options that vary by vehicle make and model.

  • Page 58: Re-Flash Errors

    Typical reprogramming operations require you to input and validate VIN number first. Tap the input box and enter the correct number. The programming interface then displays. The main section of the reprogramming interface offers information of the hardware, the current software version and the newest software versions to be programmed into the control units.

  • Page 59: General Procedure

    4.8.1 General Procedure ➢ To access the OBDII/EOBD diagnostics functions Tap the Diagnostics button from the MaxiSys Job Menu. The Vehicle Menu displays. Tap the EOBD button. There are three options to establish communication with the vehicle. Auto Scan General — select it to establish communication using each ⚫...

  • Page 60: Function Descriptions

    Component Test ⚫ Vehicle Information ⚫ Vehicle Status ⚫ NOTE The supported functions may vary by vehicles. 4.8.2 Function Descriptions This section describes the various functions of each diagnostic option: 4.8.2.1 DTC & FFD When this function is selected, the screen displays a list of Stored Codes and Pending Codes.
  • Page 61 Freeze Frame ⚫ In most cases the stored frame is the last DTC reported. Certain DTCs, those that have a greater impact on vehicle emission, have a higher priority. In these cases, DTC of the highest priority is the one for which the freeze frame records are retained. Freeze frame data includes a "snapshot"...

  • Page 62: Diagnostic Report

    vehicles, refer to On-Board Monitor. 4.8.2.5 On-Board Monitor This function allows you to view the results of On-Board Monitor tests. The tests are useful after the service when a vehicle's control module memory is already erased. 4.8.2.6 Component Test This function enables dual-directional control of the ECM so that the diagnostic tool can transmit control commands to operate the vehicle systems.

  • Page 63: Diagnostics Report Saving, Viewing, And Sharing

    ⚫ Post-Scan Function After the pre-scan is complete, exit the current test vehicle and tap the vehicle button from the Vehicle Menu screen to reconnect again. Enter the same maintenance order number in the pop-up box. The screen for post-scan will display. The post- scan record will be generated when the scan is completed.
  • Page 64 Figure 4-22 Historical Test Screen Tap Get Report. Enter the license plate and current mileage. Tap Save. ⚫ Via the Auto Scan function Enter the Auto Scan page and tap Fault Scan from the function buttons at the bottom of the screen. Figure 4-23 Auto Scan Screen 1 When the system scan is completed, tap Report from the function buttons at the bottom of the screen.
  • Page 65 Figure 4-24 Auto Scan Screen 2 ⚫ Via the functions on the Diagnostics Toolbar The diagnostic report can also be viewed from such diagnostics functions screen including Auto scan, Trouble codes, Live data, and Active test. There are two ways to view the saved reports: ...
  • Page 66 PDF to view these local reports. Once you save the reports by tapping the View Report or Save Report button, tap  Data Manager > Cloud Report to view these reports saved to the Autel cloud platform. 4.9.2.3 Diagnostics Report Cloud Sharing...
  • Page 67 Figure 4-26 Report List Screen NOTE Note that if the report displays , it means the report has been uploaded to the cloud successfully, and you can share the report with others; if the report displays , it means the report has failed to upload to the cloud, but will try to automatically upload to the cloud when entering the Report again.

  • Page 68: Exit Diagnostics

    4.10 Exit Diagnostics The Diagnostics application operates while communication with the vehicle is still active. It is important to properly exit from the diagnostics operation screen to stop all communications with the vehicle before closing the Diagnostics application. NOTE Damage to the vehicle Electronic Control Module (ECM) may occur if communication is disrupted.

  • Page 69: Service

    Service The Service section is specially designed to provide quick access to the vehicle systems for various scheduled service and maintenance tasks. The typical service operation screen is a series of menu driven executive commands. Follow on-screen instructions to select appropriate execution options, enter correct values or data, and perform necessary actions.

  • Page 70: Electric Parking Brake (Epb) Service

    Ensure that the EPB control system is reactivated after the maintenance work has been completed. NOTE Autel accepts no responsibility for any accident or injury arising from the maintenance of the Electric Parking Brake system. 5.3 Tire Pressure Monitoring System (TPMS) Service...

  • Page 71: Battery Management System (Bms) Service

    5.4 Battery Management System (BMS) Service The Battery Management System (BMS) allows the tool to evaluate the battery charge state, monitor the close-circuit current, register the battery replacement, activate the rest state of the vehicle, and charge the battery via the diagnostic socket. NOTE This function is not supported by all vehicles.

  • Page 72: Immobilizer (Immo) Service

    The oil for diesel is not contaminated. ⚫ IMPORTANT Before diagnosing the problematic vehicle and attempting to perform an emergency regeneration, it is important to obtain a full diagnostic log and read out relevant measured value blocks. NOTE The DPF will not regenerate if the engine management light is on, or there is a faulty EGR valve.

  • Page 73: Steering Angle Sensor (Sas) Service

    Accident repairs where damage to the SAS or assembly, or any part of the steering system may have occurred. NOTE Autel accepts no responsibility for any accident or injury arising from servicing the SAS system. When interpreting DTCs retrieved from the vehicle, always follow the manufacturer's recommendation for repair.

  • Page 74: Data Manager

    Data Manager The Data Manager application allows you to store, print, and review the saved files, manage the workshop information, and customer information records, and keep test vehicle history records. Selecting the Data Manager application opens the file system menu. There are nine main functions available.

  • Page 75: Vehicle History

    Button Name Description Tap to review the saved reports and share Cloud Report cloud reports. Tap to review the reports stored as PDF files. Review Data Tap to review the recorded data. Tap to review the communication data and ECU information of the vehicle. The saved Data Logging data can be reported and sent to the technical center via the Internet.

  • Page 76: Historical Test Record

    Top Toolbar Buttons — navigation and application controls. Main Section — displays all the vehicle history records. ➢ To activate a test session for the recorded vehicle Tap Data Manager on the MaxiSys Job Menu. Select Vehicle History to open the screen. Tap the relevant application tab to select the test record.

  • Page 77: Workshop Information

    ➢ To edit the Historical Test record Tap Data Manager on the MaxiSys Job Menu. Select Vehicle History. Select the specific vehicle history record thumbnail from the main section. The Historical Test record will display. Tap Edit (a pen icon) to start editing. Tap each item to input information or attach files or images.

  • Page 78: Customer

    ➢ To edit the Workshop Information sheet Tap the Data Manager application on the MaxiSys Job Menu. Select Workshop Information. Tap on each field to input the appropriate information. Tap Done to save the updated workshop information record, or tap Cancel to exit without saving.

  • Page 79: Image

    Select a customer account by tapping the corresponding name card. A Customer Information record displays. Tap Edit on the top toolbar to start editing. Tap the Delete button on the top of the screen. A reminder message displays. Tap OK to confirm the command, and the account is deleted, or tap Cancel to cancel the request.

  • Page 80: Cloud Report

    Button Name Description Cancel Tap to close the editing toolbar or cancel file search. Print Tap to print the selected image. Delete Tap to delete the selected image. Email Tap to send the selected image to an email. ➢ To edit/delete image(s) Select Data Manager from the MaxiSys Job Menu.

  • Page 81: Data Logging

    Figure 6-6 Data Playback Screen Main Section — displays the recorded data frames. Navigation Toolbar — allows you to manipulate data playback. Use the Navigation Toolbar buttons to play back the record data from frame to frame. Tap Back to exit data playback. 6.8 Data Logging The Data Logging section allows you to launch Support platform directly to view all records of all feedback or no feedback data loggings on the diagnostic system.

  • Page 82: Settings

    Settings Access the Settings menu to adjust default setting and view information about the MaxiSys system. The following options are available for the MaxiSys system settings: Unit ⚫ Language ⚫ Printing Settings ⚫ Scan Report ⚫ Push Notifications ⚫ Auto Update ⚫...

  • Page 83: Print Settings

    To install the MaxiSys Printer driver Download Maxi PC Suite from www.autel.com > Support > Downloads > Autel Update Tools, and install it to a Windows-based PC. Double click on Setup.exe. Select the installation language and the wizard will load.

  • Page 84: Scan Report

    Tap the Print button in the tablet top toolbar. A document will be sent to the computer. If the Auto Print option in the MaxiSys Printer is selected, the MaxiSys ⚫ Printer will print the received document automatically. ⚫ If the Auto Print option is not selected, click Open PDF File button to view files.

  • Page 85: Auto Update

    down list. There are four options: Enable all notifications, Limit to 3 notifications or less per week, Limit to 1 notification per week, and Disable all notifications. Select whichever you want. Tap Home on the top-left corner to return to the MaxiSys Job Menu, or select another settings option for the system setup.

  • Page 86: System Settings

    7.8 System Settings This function provides you with direct access to the Android system setting interface, where you can adjust various system settings for the Android system platform. Regarding wireless and networks settings, various device settings such as sound and display, as well as system security settings, and check related information about the Android system.

  • Page 87: Vci Manager

    VCI Manager This application pairs the tablet with the VCI device, checks the communication status and updates the VCI firmware. Figure 8-1 VCI Manager Screen Connection Mode — there are four connection modes available for selection. The connection status is displayed alongside. ⚫...

  • Page 88: Vci Bluetooth Pairing

    8.1 VCI Bluetooth Pairing The VCI device needs to be connected to a vehicle, so that it is powered during the synchronization procedure. Ensure the tablet has sufficient battery power or is connected to an external power supply. To pair the VCI device with the tablet ➢...

  • Page 89: Vci Update

    Download the Maxi PC Suite software from www.autel.com > Support > Downloads > Autel Update Tools, and install it onto your PC. Connect the VCI device to the PC via Bluetooth. Launch the Maxi PC Suite after installation and click the VCI device icon in the Device Selection window.
  • Page 90 ➢ To update the battery tester’s firmware Power on the diagnostic tablet and the battery tester. Connect the battery tester to the tablet via Bluetooth. Tap the VCI Manager application on the MaxiSys Job Menu of the tablet. Select BAS Update from the Connection Mode list on the left column. The current version and the latest version of the battery tester’s firmware will be displayed after a few seconds.

  • Page 91: Support

    If you have an Autel account, sign in with your account ID and password and skip to step 7. If you are a new member to Autel, click the Register button to create your Autel Enter the required personal information in the input fields.

  • Page 92: My Account

    Information section. User Information — displays detailed information of your registered online Autel ⚫ account, such as your Autel ID, name, address, and other contact information. Device Information — displays the registered product information, including the ⚫ product serial number, registration time, expired time, and warranty period.

  • Page 93: Training

    Every time the device has been sent back to Autel for repair, the device's serial number and the detailed repair information, such as the fault type, changed components, or system reinstallation will be recorded and updated to the associated online product account that will be synchronized to the Service Information section.

  • Page 94: Faq

    9.7 FAQ The FAQ section provides comprehensive references for all questions frequently asked and answered about the use of Autel’s online member account and shopping and payment procedures. Account — displays questions and answers about the use of Autel's online user ⚫...

  • Page 95: Remote Desktop

    You can use the application to receive ad-hoc remote support from Autel’s support center, colleagues, or friends, by allowing them to control your MaxiSys tablet on their PC via the TeamViewer software.
  • Page 96 Your partner must install the Remote Control software to his/her computer by downloading TeamViewer full version program online (http://www.teamviewer.com), and then launch the software. Provide your ID to the partner, and wait for him/her to send you a remote-control request. A message will appear asking for your confirmation to allow remote-control on your device.

  • Page 97: Update

    Update The Update application on the tablet downloads the latest version of the software. The updates improve the MaxiSys applications’ capabilities, typically by adding new tests, new model coverage or by adding new or enhanced applications. The tablet automatically searches for available updates for all of the MaxiSys software when it is connected to the Internet.
  • Page 98 Middle Column — displays a brief introduction about the new changes to the ⚫ firmware operation or capabilities. Tap the button to open an information screen to view more details, and tap the dim area around to close the window. Right Column —...

  • Page 99: Quick Link

    Quick Link The Quick Link application provides you with convenient access to Autel’s official website and many other well-known sites in automotive service industry to provide technical help, knowledge bases, forums, and training and expertise consultations. Figure 12-1 Quick Link Screen ➢...

  • Page 100: User Feedback

    Tap Submit to send the completed information to Autel's online service center. The submitted feedback will be carefully read and handled by our service...

  • Page 101: Maxiviewer

    MaxiViewer The MaxiViewer application allows you to search the functions supported by our tools and the version information. There are two ways for searching, either by searching the tool and the vehicle or searching the functions. ➢ To search by the vehicle Tap the MaxiViewer application on the MaxiSys Job Menu.

  • Page 102: Maxivideo

    MaxiVideo The MaxiVideo application configures the MaxiSys tablet to operate as a digital video scope by simply connecting the tablet to a MaxiVideo Digital Inspection Camera. This function allows you to examine difficult-to-reach areas normally hidden from sight, with the ability to record digital still images and videos, which offers you an economical solution to inspect machinery, facilities, and infrastructure in a safe and quick way.

  • Page 103: Maxiscope

    For details about the MaxiScope function, see www.autel.com > Products > Specialty Tools > MaxiScope MP408 > Downloads.

  • Page 104: Battery Test

    Battery Test The Battery Test application allows the user to perform in-vehicle battery test and out- vehicle battery test functions when the BT506 battery tester is connected to the MaxiSys tablet and a battery. The BT506 battery tester enables technicians to view the health status of the vehicle’s battery and electrical system.

  • Page 105: Maxibas Bt506 Battery Tester

    17.1 MaxiBAS BT506 Battery Tester 17.1.1 Function Description Figure 17-2 MaxiBAS BT506 Tester Power Button Status LED Power LED USB Port Battery Clamp Cable Table 17-1 LED Description Color Description The tester is communicating via USB Flashing Green cable. tester communicating Status LED Flashing Blue...

  • Page 106: Power Sources

    Color Description The tester is powered on and the battery Solid Green is sufficiently charged. The tester is charging. (Turns solid Flashing Green green when battery is fully charged.) Power LED Solid Red The device is in boot mode. Flashing Red The battery level is low.

  • Page 107: Test Preparation

    Item Description CCA Range 100 to 2000 A Voltage Range 1.5 to 16 V －10 °C to 50 °C (14 °F to 122 °F) Working Temp. －20 °C to 60 °C (－4 °F to 140 °F) Storage Temp. 107 mm (4.21”) x 75 mm (2.95”) x 26 mm (1.02”) (clamp Dimension (L x W x H) cable not included)

  • Page 108: In-Vehicle Test

    Figure 17-3 Battery Tester Connection Example 1 ➢ To connect to a battery Connect the red clamp to the positive (+) terminal of the battery. Connect the black clamp to the negative (−) terminal of the battery. Figure 17-4 Battery Tester Connection Example 2 17.4 In-vehicle Test The In-vehicle Test is used for testing batteries that are installed in a vehicle.
  • Page 109 ➢ To start the in-vehicle test Tap Battery Test on the MaxiSys Job Menu. Select In-vehicle Test. Confirm the vehicle information on the left side of the screen. Make sure the VIN is entered. Confirm your battery information, including voltage, type, standard, and capacity. Tap Next to continue in-vehicle test functions.

  • Page 110: Battery Test

    Button Name Description Exit Returns to the Job Menu. 17.4.1 Battery Test Follow the on-screen instructions. Check the boxes once all required tasks are completed, and tap Start Testing. Figure 17-6 Battery Screen Wait until the test is completed. The test results will be displayed on the tool.

  • Page 111: Starter Test

    Figure 17-7 Battery Test Results Screen The battery test results include a color-coded results summary, a list of test data, and repair tips: Table 17-4 Test Results Result Repair Tip Good Battery Battery is good. Good & Battery is good but insufficiently charged. Recharge the battery. Recharge Charge &...

  • Page 112: Generator Test

    Figure 17-8 Starter Test Result Screen Table 17-5 Starter Test Results Result Description Cranking Normal The starter is good. Current Too Low Low momentary discharge capacity. Voltage Too Low Low battery storage capacity. Not Started The starter is not detected for starting. 17.4.3 Generator Test Follow the on-screen instructions to complete the test.
  • Page 113 Figure 17-9 Generator Test Results Screen Table 17-6 Generator Test Results Result Description Charging Normal The generator is functioning normally. The belt linking the starter and the generator is ⚫ loose; Output Too Low ⚫ The cable linking the starter and battery is loose or corroded.

  • Page 114: Out-Vehicle Test

    17.5 Out-vehicle Test Out-vehicle Test is used to test the condition of batteries that are not connected to a vehicle. This function aims to check the health status of the battery only. 17.5.1 Test Procedure ➢ To start the out-vehicle test Connect the tester clamps to the battery terminals.

  • Page 115: Test Results

    Figure 17-11 Out-vehicle Test Results Screen 17.5.2 Test Results Table 17-7 Out-Vehicle Test Results Result Description Good Battery Battery meets required standards. Battery is good, but low on charge. Fully charge Good & Recharge the battery. Check for causes of low charge. Charge &...

  • Page 116: Autel User Center

    Figure 18-1 Autel User Center Screen If you already have an Autel ID, you can log in with your phone number and verification code, or tap Log In with Password to log in with your Autel ID and password. If you don't have an Autle ID yet, tap Register to create an Autel ID.

  • Page 117: Maintenance And Service

    Maintenance and Service To ensure that the tablet and the combined VCI unit perform at their optimum level, we advise that the product maintenance instructions covered in this section are strictly followed. 19.1 Maintenance Instructions The following includes how to maintain your devices, together with precautions to take. Use a soft cloth and alcohol or a mild window cleaner to clean the touchscreen of ⚫...

  • Page 118: Troubleshooting Checklist

    Your device may have not been connected to the charger properly. Check the ⚫ connector. NOTE If the problems persist, please contact Autel's technical support personnel or your local selling agent. 19.3 About Battery Usage Your tablet is powered by a built-in lithium-ion polymer battery, which enables you to recharge your battery when there is electricity left.

  • Page 119: Service Procedures

    Do not modify, remanufacture or attempt to insert foreign objects into the battery, or ⚫ expose the battery to fire, explosion, or other hazards. Only use the specified charger and USB cables. Use of non-Autel-authorized charger ⚫ or USB cables may lead to device malfunction or failure.
  • Page 120 ⚫ Address: 7th, 8th and 10th Floor, Building B1, Zhiyuan, Xueyuan Road, Xili, Nanshan, Shenzhen, 518055, China ⚫ Web: www.auteltech.cn Autel Latin America ⚫ Phone: +52 33 1001 7880 (Spanish in Mexico)，+55 19 97816 4911 (Portuguese in Brazil) ⚫ Email: latsupport@autel.com...

  • Page 121: Repair Service

    For technical assistance in other markets, please contact your local selling agent. 19.4.2 Repair Service If it becomes necessary to return your device for repair, please download the repair service form from www.autel.com, and fill in the form. The following information must be included: ⚫...
