Button Name
Home
Vehicle Swap
Settings
Print
Help
Save
Data Logging
NOTE
The Diagnostics Toolbar buttons (located on the top of the screen) will be active
throughout the diagnostics session for such tasks as printing and saving the displayed
data, obtaining help information or performing data logging.

To print data in Diagnostics
1. Tap the Diagnostics application button on the MaxiSys Job Menu. The Print
button on the diagnostics toolbar is available throughout the Diagnostics
operations.
2. Tap Print and a drop-down menu displays.
Print This Page — prints a screenshot of the current screen.
a)
Print All Data — prints a PDF copy of all displayed data.
b)
3. A temporary file will be created and sent via the computer to the printer.
4. When the file is sent, a confirmation message appears.
Table 4-2 Diagnostics Toolbar Buttons
Description
Returns to the MaxiSys Job Menu.
Exits the diagnostics session and returns to the
vehicle menu screen to select another vehicle for
testing.
Opens the Settings screen. See
Saves and prints a copy of the displayed data. See
Printing Settings.
Provides instructions or tips for operations of various
diagnostics functions.
Opens a submenu which provides options for data
storage.
Use this function when encountering an error during
test or diagnosis. This function will record the
communication data and ECU information of the test
vehicle and send it to Autel technical staff to review
and provide a solution.
Go to the Support application to view the processing
progress. See Data Logging.
27
Settings.
