5. Tap OK to save the settings and return to the Live Data screen, or tap Cancel
to exit without saving.
When the trigger is successfully set, a trigger mark displays in front of the parameter.
The mark is gray when it is not triggered, and displays orange when triggered. Moreover,
two horizontal lines display on each of the data graphs (when Waveform Graph Mode is
applied) to indicate the threshold values. The limit lines are shown in different colors to
differentiate them from the parameter waveforms.
3. Function Buttons
The operations of the function buttons on the Live Data screen are described below:
 Group — tap to set the selected parameters to the same group.
 Cancel All — tap to cancel all selected parameters. Up to 50 parameters can be
selected at one time.
 Show Selected/Show All — tap to toggle between the two options; one displays
the selected parameters, the other displays all the available items.
 Graph Merge — tap to merge selected data graphs (for Waveform Mode only). This
function is very useful when comparing different parameters.
NOTE
This mode supports a Graph Merge of 2 to 5 digital parameters. Non-digital parameters
are not supported.

To merge selected data graphs
1. Select parameters to be merged.
2. Tap the Graph Merge button at the bottom of the Live Data screen.
a) This mode only supports parameters that can be represented digitally. If
non-digital parameters are selected, a message will display advising the
user that the selected parameters are not supported in this mode and to
select 2 to 5 digital parameters. Tap the Got It button to return to the
previous screen and select supported parameters.
b) If selected parameters are not supported in this mode, a message will
display advising the user to select only parameters that are supported. A
message will also display if more than 5 parameters have been selected.
Please select 2 to 5 of the supported parameters and tap the OK button
to merge.
