Models

The presentation switchers are available in the following models:
Model
DTP2 CrossPoint 82
DTP2 CrossPoint 82 IPCP SA
DTP2 CrossPoint 82 IPCP MA 70

Integrated Digital Twisted Pair Extension

The DTP2/XTP inputs and DTP2/XTP/HDBT outputs are proprietary signals that are created within any of the
Extron DTP Extender systems and transmitted over a single shielded twisted pair (STP) cable.
Depending on the range of the transmitting or receiving device, the twisted pair (TP) inputs and outputs can each
travel up to 330 feet (100 meters) without a loss of signal integrity. They also support IR (output only) and RS-232
insertion, and dedicated universal asynchronous receivers and transmitters (UARTs).
Shielded twisted pair cabling with solid center conductor sizes of 24 AWG or better is recommended for optimal
performance.
NOTE: Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for optimal performance.
• Input —The DTP2 CrossPoint 82 can receive signals from a remote DTP or DTP2 transmitter (such as the
DTP T USW 333) at a conference table, lectern, or wall. It can also be integrated into an XTP CrossPoint
matrix switcher system.
• Output —The DTP2 CrossPoint 82 can transmit to a DTP or DTP2, XTP, or HDBaseT receiver or directly to
an HDBaseT enabled display device. It can also be integrated into an XTP CrossPoint matrix switcher
system.
• Power over DTP —The DTP2 CrossPoint 82 can send power to selected DTP or DTP2 endpoints over the
same shielded CATx cable, streamlining system design and installation.
DTP transmitters and receivers are available in compact, low-profile enclosures, and in decorator-style wallplate
and floorbox versions to suit the installation requirements of a specific application.
RS-232 and IR signal insertion
The DTP2 inputs and output support bidirectional Ethernet to RS-232 insertion. Ethernet insertion allows you to
employ Ethernet drivers from either the local controller (IPCP models only) or an external controller connected on
the IP network.
IR output signals can be inserted from a control system and transmitted over the single shielded CATx cable
together with the video and audio, enabling control of a display.
Matrix switcher integration
In addition to supporting DTP endpoints, the DTP2 CrossPoint 82 can be integrated into an XTP CrossPoint
matrix switcher system. This enables facility-wide AV system applications with a centralized AV signal distribution
infrastructure, as well as several presentation spaces with local AV switching and processing.
Description
Base model
1U high
Stereo amplifier model
2U high
70 V mono amplifier model
2U high
DTP2 CrossPoint 82 Scaling Presentation Matrix Switchers • Introduction
Inputs Outputs
1 DisplayPort 1 HDMI
5 HDMI 1 DTP2/XTP/HDBT
2 DTP2/XTP 1 HDMI Loop Out
1 DisplayPort 1 HDMI
5 HDMI 1 DTP2/XTP/HDBT
2 DTP2/XTP 1 HDMI Loop Out
1 DisplayPort 1 HDMI
5 HDMI 1 DTP2/XTP/HDBT
2 DTP2/XTP 1 HDMI Loop Out
