10.9 Cylinder gas supplies

8
2
6
Item Description
1 Gas supply O
2
Gas supply N
2
Gas supply Air, Pin Index
2 Screw, M6x25 socket head cap (3 per supply)
Lockwasher, M6 external (for above screw)
3 Cylinder inlets (Pin Index)
3a Gasket
3b* O-ring
3c Adapter, inlet
3d Filter, sintered bronze
3f Retaining ring, filter
4 Clamp, yoke
5 Tee handle beige
6 Spacer, gas block (2)
Screw, M8 x 25 long socket head cap (2)
7 Elbow fitting for cylinder pressure gauge (copper tube connection of gas
supply)
8 Label Set, cylinder supply, O
Label Set, cylinder supply, N
Label Set, cylinder supply, Air
* Lubricate sparingly with Krytox
M1207026
M1207027
Reproduced from the electronic master in MATRIX
7
1
3
4
5
, Pin Index
O, Pin Index
2
O
2
004 MANUAL−DOC, Technical Reference Manual, Technical Reference Manual for 9100c, English
10 Illustrated Parts
3a 3b 3c 3d
Stock number
1006-3201-000
1006-3225-000
1006-3203-000
M1168570-S
9213-0560-003
--------------------
0210-5022-300
9221-3013-116
1001-4075-000
9914-6380-000
1001-5954-000
1001-4076-000
0219-3372-600
1001-4077-000
9211-0680-253
1006-3713-000
1006-3854-000
1006-3855-000
1006-3856-000
3e
