Annex 6: System Turn OFF Process List

Tick after
No.
completion
☐
1
☐
2
☐
3
☐
4
☐
5
Turn off the switch between INVERTER and this
battery string (PowerCube-M1-C), or turn off the power
switch of INVERTER, to make sure no current through
this battery string.
Turn off the "Power Output Switch" of the BMS.
Turn off the "Power Switch" of the BMS.
Turn off the "Power Switch" of the MBMS.
Turn off the UPS.
The UPS can be turned on to check the equipment
(INVERTER or battery system etc.). Otherwise, be sure to
turn off the UPS to save its power.
Item
116
Remark
Refer to section
3.6.4.
Refer to section
3.6.5.
Refer to section
3.6.5.
Refer to section
3.6.5.
Refer to section
3.6.5.
