Annex 5: Installation and System Turn ON Process List

Tick after
No.
completion
☐
1
☐
2
☐
3
☐
4
☐
5
☐
6
☐
7
☐
8
☐
9
☐
10
☐
11
☐
13
The environment is meeting all technical requirements.
3.3.1
Cleaning
3.3.2
Temperature
3.3.3
Radiating System
3.3.4
Heating System
3.3.5
Fire-extinguisher System
3.3.6
Grounding System
Battery rack is installed following the technical
requirements.
Control Module (BMS) and Battery Module are installed
well.
And install the rack metal strip.
The MBMS are installed well. (If configured.)
The Ethernet Switch is installed well. (If configured.)
Connect the AC power cables from BMS, MBMS and
Ethernet Switch to the AC "OUT PUT" socket of the UPS.
(If c o n f i g u r e d .)
Connect External Power Cable +/- between each BMS
to the INVERTER or confluence cabinet.
Connect power cables of each battery string.
Connect communication cables of each battery s t r i n g . Refer to section
Set up ADD switch of every BMS and the MBMS
( Address Assignment).
Connect external communication cables from BMS t o
Ethernet Switch, MBMS or another.
Connect the communication cable from MBMS to the
INVERTER.
Item
114
Remark
Refer to section
3.3
Refer to section
3.5.3.
Refer to section
3.5.4.
Refer to section
3.5.5.
Refer to section
3.5.6.
Refer to section
3.6.2.1 or 3.6.2.2.
Refer to section
3.6.2.1 or 3.6.2.2.
Refer to section
3.6.2.1 or 3.6.2.2.
3.6.2.1 or 3.6.2.2.
Refer to section
3.6.3.
Refer to section
3.6.2.1 or 3.6.2.2.
Refer to section
3.6.2.1 or 3.6.2.2.
