2.3.1.1 Inverter Components (30K-3P-208V/60K-3P-480V)
1.
Inverter Indicators
4.
ON/OFF Button
7.
Parallel Port
10.
BMS Port
13.
Grid Connection
16.
Wi-Fi Interface
2.
LCD Display (Touch)
5.
2 x PV Disconnect
8.
CAN Port
11.
RS485 Port
14.
Function Port
17.
Load Connection
15
3.
Function Buttons
6.
Meter Port (optional)
9.
Ground / Neutral Bars
12.
Generator Input
15.
PV Input MPPTs
18.
Battery Connections
