3.1.3
Internal Layout
Following is the layout of a 30Kw system with up to two BMS units and two battery strings. Other
configurations can also refer to this drawing, only differs on the Qty. of BMS units and battery
modules.
BMS 1
⑬
Battery Module
BMS 2
37
MBMS
AC Breaker
UPS
DRL 24V,12V power switch
Intermediate Relay
AC SPD Breaker
QF2(AC Breaker2)
QF1(AC Breaker 1)
⑪
150A-8 Pin TC terminal
⑫
3 kVA Transformer
⑭
Aerosol Fire Suppression Device
