5. Installation

5.1 Check for Physical Damage

Make sure the inverter is intact during transportation. If there is any visible
damage, such as cracks, please contact your dealer immediately.

5.2 Packing List

Open the package and take out the product, please check the accessories first.
The packing list shown as below.
A
F
K
Object Quantity
A 1
B 2
C 6
D 6
E 2
F 6
G 1
atx002en0723
B
G
L
Description
Inverter
Brackets
PV connectors (Only for 3ph)
(3*positive, 3*negative)
PV pin contacts (Only for 3ph)
(3*positive, 3*negative)
AC connectors
Expansion tubes &
Expansion screws
Earth terminal
C
Quick
installation
guide
H
M
Object Quantity
H 1
I 1
J 1
K 1
L 3
M 2
N 2
D
I
N
Description
Communication connector
Quick installation guide
WiFi/GPRS/LAN (Optional)
Meter
Hexagonal screws
Battery connectors
(1*positive, 1*negative)
Battery pin contacts
(1*positive, 1*negative)
E
J
