a-TroniX Inverter AX-series, 3 ph
Work modes:
Work modes
Self-use
(with PV Power)
Self-use
(without PV
Power)
Feed in priority
Back up mode
Power station
NOTE
Charging time is when the battery is charged within the set time range.
The setting of charging time can be used in the above three modes.
Page 84
Description
Priority: load>battery>grid
The energy produced by the PV system is used to optimize
self-consumption. The excess energy is used to charge the
batteries, then exported to gird.
When no PV supplied, battery will discharge for local loads
firstly, and grid will supply power when the battery capacity is
not enough.
Priority: load>grid>battery
In the case of the external generator, the power generated
will be used to supply the local loads firstly, then export to the
public grid. The redundant power will charge the battery.
When the grid is off, system will supply emergency power from
PV or battery to supply the home loads (Battery is necessary in
EPS mode).
The energy of the battery is used to suppress the output power
instability caused by the unstable output of the photovoltaic
panel, so that the power output of the inverter reaches the
ideal power curve.
