4. Technical Data

4.1 PV Input (For 3ph Only)

Model AX
PV
Max. recommended DC power [W]
Max. DC voltage [V]
Nominal DC operating voltage [V]
Max. input current (input A / input B) [A]
Max. short circuit current (input A / input B) [A]
MPPT voltage range [V]
MPPT voltage range (full load) [V]
Start-up voltage [V]
No. of MPP trackers
Strings per MPP tracker

4.2 Battery

Model AX
Battery
Battery type
Battery voltage [V]
Full AC load Battery voltage [V]
Max. Charge/ discharge current [A]
Communication interface
[1] Minimum operation battery voltage is 120 V.
atx002en0723
5kW 6kW 8kW
7500 9000 10400
1000
720
14 / 14
16 / 16
160-950
210-800 250-800 240-800 280-800 320-800
160
1 + 1
5kW 6kW 8kW
LFP battery
180-600 [1]
205 250 330
26,0
CAN / RS485
10kW 12kW
13000 15000
26 / 14
32 / 16
2
2 + 1
10kW 12kW
410 480
