4.3 AC Output/Input
Model AX
AC OUTPUT
Nominal AC power [VA]
Max. apparent AC power [VA]
Rated grid voltage (AC voltage range) [V]
Rated grid frequency [Hz]
Max. AC current [A] (Per phase)
Power Factor
Export Control
AC inrush current [A]
Max. output fault current [A]
Max. output overcurrent protection [A]
THDI
AC INPUT
Max. AC power [VA]
Rated grid voltage (AC voltage range) [V]
Rated grid frequency [Hz]
Max. AC current [A] (Per phase)
AC inrush current [A]
Power Factor
Page 88
5kW 6kW 8kW
5000 6000 8000
5500 6500 8800
400V/230VAC; 380V/220VAC, 3L/N/PE
50 / 60, ±5
8,0 9,6 12,8
1 (Adjustable from 0.8 leading to
0.8 lagging)
Yes
15A@0.5ms
150A@0.5ms
45
<3%@rated power
10000 12000
400V/230VAC; 380V/220VAC, 3L/N/PE
50 / 60, ±5
15,2 18,2
15A@0.5ms
1 (Adjustable from 0.8 leading to
0.8 lagging)
10kW 12kW
10000 12000
11000 13200
16,0 19,2
16000
24,2
