3.3 Terminals of inverter

Item Description
A DC Switch
B PV1
C PV2
D PV3
E Battery Connector
F USB / WiFi / GPRS / LAN
G Waterproof Lock Valve
H PARALLEL 1
I GRID
J Meter / RS485
K BMS
L DRM
M PARALLEL2
N EPS
O Grounding Screw
NOTE
Only authorized personnel are permitted to set the connection.
