General compensation value data (kw.*)
Remarks
3.2.13

Manual activation (P-COMP-00030)

P-COMP-00030 Manual activation
Description Plane compensation is automatically activated by the CNC if it selected in the axis
parameters (P-AXIS-00174) and the required conditions are met (e.g. axis is
homed).
If the parameter is set to value 1, plane compensation must be activated explicitly by
an NC command (see [PROG//Selecting/deselecting axis compensations in the NC
program]. In addition, compensation is deselected at the end of the NC program, at
CNC reset and on axis release.
Parameter kw.crosscomp2.manual_activation
Data type BOOLEAN
Data range 0: Automatic activation
1: Manual activation in NC program
Axis types T, R, S
Dimension T: ----
Default value 0
Remarks
22
R,S: ----
