- Page 1 Manual | EN TF5200 | TwinCAT 3 CNC Clamp position offsets 7/8/2021 | Version: 1.13...
- Page 3 EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702 with corresponding applications or registrations in various other countries. ® EtherCAT is registered trademark and patented technology, licensed by Beckhoff Automation GmbH, Germany Copyright © Beckhoff Automation GmbH & Co. KG, Germany. The reproduction, distribution and utilisation of this document as well as the communication of its contents to others without express authorisation are prohibited.
-
Page 4: General And Safety Instructions
Programming example (complete NC program or program sequence) of the described function or NC com- mand. Specific version information Optional or restricted function. The availability of this function depends on the configuration and the scope of the version. Version: 1.13 TF5200 | TwinCAT 3 CNC Clamp position offsets... -
Page 5: Table Of Contents
2.1.1 Axis assignment of data in the clamp position offset group (pzv_grp[i].achse[j.*]) .. 10 3 Example of assigning clamp position offset data ("pzv_d.lis") ............ 11 4 Support and Service.......................... 12 Index ................................. 13 TF5200 | TwinCAT 3 CNC Version: 1.13 Clamp position offsets... - Page 6 Table of contents Version: 1.13 TF5200 | TwinCAT 3 CNC Clamp position offsets...
-
Page 7: Overview Of Clamp Position Offset Parameter
• Column 4 contains the “functionality” in a summarised term/short description, e.g. Axis-specific clamp position offset. Structure Parameter Functionality/short description pzv_grp[i].achse[j]. offset Axis-specific clamp position P-CLMP-00001 [} 10] offset TF5200 | TwinCAT 3 CNC Version: 1.13 Clamp position offsets... -
Page 8: General Description
ASCII list file. The following agreement applies to BOOLEAN data: Value Meaning Definition of FALSE Definition of TRUE Version: 1.13 TF5200 | TwinCAT 3 CNC Clamp position offsets... -
Page 9: Comments In The Ascii List File
# ************************************************************************ # Data # ************************************************************************ # Listing dummy[1] 1 Comment dummy[2] 1 # Comment dummy[3] 1 ( Comment dummy[4] 1 /* Comment beispiel[0].bezeichnung STRING_2 (Comment: comment brackets required here!) TF5200 | TwinCAT 3 CNC Version: 1.13 Clamp position offsets... -
Page 10: Description Of Elements
An offset parameter is reserved for each axis in each clamp position offset group. Parameter pzv_grp[i].achse[j].versatz Data type SGN32 Data range MIN(SGN32) ≤ versatz ≤ MAX(SGN32) Dimension 0.1µm or 0.0001° Default value Remarks Version: 1.13 TF5200 | TwinCAT 3 CNC Clamp position offsets... -
Page 11: Example Of Assigning Clamp Position Offset Data ("Pzv_D.lis")
# ============================================================================ # 3rd clamp position offset group # ============================================================================ pzv_grp[2].achse[0].versatz 40000 # Offset by 4 mm pzv_grp[2].achse[1].versatz 50000 # Offset by 5 mm pzv_grp[2].achse[2].versatz 60000 # Offset by 6 mm TF5200 | TwinCAT 3 CNC Version: 1.13 Clamp position offsets... -
Page 12: Support And Service
Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet pages: https://www.beckhoff.com You will also find further documentation for Beckhoff components there. -
Page 13: Index
Index Index P-CLMP-00001 10 TF5200 | TwinCAT 3 CNC Version: 1.13 Clamp position offsets... - Page 15 More information: www.beckhoff.com/TF5200 Beckhoff Automation GmbH & Co. KG Hülshorstweg 20 33415 Verl Germany Phone: +49 5246 9630 info@beckhoff.com www.beckhoff.com...
