- Page 1 Functional description | EN TF5200 | TwinCAT 3 CNC Online tool compensation 6/8/2021 | Version: 1.02...
- Page 3 EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702 with corresponding applications or registrations in various other countries. ® EtherCAT is registered trademark and patented technology, licensed by Beckhoff Automation GmbH, Germany Copyright © Beckhoff Automation GmbH & Co. KG, Germany. The reproduction, distribution and utilisation of this document as well as the communication of its contents to others without express authorisation are prohibited.
-
Page 4: General And Safety Instructions
Programming example (complete NC program or program sequence) of the described function or NC com- mand. Specific version information Optional or restricted function. The availability of this function depends on the configuration and the scope of the version. Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation... -
Page 5: Table Of Contents
Channel-specific connection.................... 26 2.7.2 Axis-specific connection .................... 28 Special V.G. variables for OTC ....................... 30 Connecting to external tool management .................. 31 3 Parameter .............................. 32 Overview............................ 32 Description............................ 32 4 Support and Service.......................... 34 Index ................................. 35 TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation... - Page 6 Table of contents Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation...
- Page 7 Figure 9 Grinding disc setting B=0......................Figure 10Grinding disc setting B=90......................Figure 11Description of TOOL_DIR function ....................Figure 12Wear in surface normal direction ....................Figure 13Description of SURF_NORM_DIR function ................. TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation...
-
Page 8: Overview
Programming Manual or P-AXIS-00001 for an axis parameter. For technical reasons, these links only function in the Online Help (HTML5, CHM) but not in pdf files since pdfs do not support cross-linking. Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation... -
Page 9: Description
The following NC command is provided to program online tool compensation in the NC program. Parametrisation can be programmed in advance or in combination with #OTC ON: #OTC ON | OFF [ [ RADIUS | LENGTH | TOOL_DIR | SURF_NORM_DIR DISC | CONT | AUTO TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation... - Page 10 Acceleration weighting in percent [1;100], default: 100% When OTC is deselected with #OTC OFF, the amount of wear (discrete and/or continuous) is in- cluded in the calculation for the current tool. Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation...
-
Page 11: Wear Compensation Of Tool Radius
Figure 2: Wear compensation of tool radius The start-up movement in relation to the equidistant path after selecting TRC (G41/G42) is con- sidered without wear. Motion after deselecting TRC (G40) is also without wear. TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation... - Page 12 N50 #OTC ON (Select OTC) N60 G41 G01 X50 (Select TRC, wear-free movement) N70 X1000 N80 G40 X50 (Deselect TRC with path motion to reduce TRC) N90 #OTC OFF (Deselect OCP) N100 G00 X50 N199 M30 Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation...
-
Page 13: Figure 3 Contour Of The Nc Program Wr_Quad_Disc.nc
Path contour with active TRC without OTC offset Black: Path contour with negative value for OTC radius offset Red: Path contour with positive value for OTC radius offset Figure 3: Contour of the NC program wr_quad_disc.nc TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation... - Page 14 If error 90050 is output, the path motion does not exist when deselected with G138/G139. The functionality of the RADIUS type is shown by the example of the G17 plane: Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation...
-
Page 15: Wear Compensation Of Tool Length
When the tool length is compensated (length compensation), wear is compensated in the direction of the 3rd main axis. This can take place both continuously and discretely. This procedure is used in particular for processing surfaces (surface grinding). TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation... -
Page 16: Figure 5 Wear Compensation Of Tool Length
Figure 5: Wear compensation of tool length Tool length wear N30 D1 (Select data set for grinding disc) N40 G00 X0 Y0 Z0 N50 #OTC ON [LENGTH] (Select OTC) N60 G1 X1000 F10000 N70 #OTC OFF (Deselect OTC) Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation... -
Page 17: Figure 6 Description Of Length Function
The LENGTH operation mode is shown in the figure below: #OTC [ LENGTH CONT/ DISC/AUTO] Decoder BAVO CONT Covered distance and tilt angle of disc G17/G18/G19 DISC Axis offset Figure 6: Description of LENGTH function TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation... -
Page 18: Inclined Grinding Disc
The figure below shows the orientation of the tilt angle using the example of the G17 plane: X/Y plane with G17 Turning point of disc negative positive is 0 Figure 7: Inclined grinding disc Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation... -
Page 19: Wear Compensation In Tool Direction
N70 G01 X100 Z50 F1000 N80 #OTC ON [TOOL_DIR, DISC] (Select OTC) N90 $FOR P1=0, 20, 1 N100 G91 G01 X10 Z-10 F2000 N110 X-10 Z10 N120 $ENDFOR N120 #OTC OFF (deselect OTC) N130 #TRAFO OFF TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation... -
Page 20: Figure 9: Grinding Disc Setting B=0
Description Programming kinematic parameters Tool 1 B=0° Grinding wheel Figure 9: Grinding disc setting B=0 Tool 2 B=90° HD10=-90° Grinding wheel Figure 10: Grinding disc setting B=90 Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation... -
Page 21: Figure 11Description Of Tool_Dir Function
Description The figure below shows the function of TOOL_DIR: #OTC [TOOL_DIR CONT/DISC/AUTO] Decoder BAVO CONT Covered distance Tool orientation Offset In tool direction DISC Figure 11: Description of TOOL_DIR function TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation... -
Page 22: Wear Compensation In Direction Of Surface Normal
This compensation type compensates for wear in surface normal direction. The surface normal direction is calculated in the CNC based on the tool direction vector and the path tangent vector. Grinding wheel ori1 Tool wear ori2 ori3 Workpiece Figure 12: Wear in surface normal direction Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation... - Page 23 N220 X-5 Z1 N230 X-5 N240 X-5 Z1 N250 X-5 Z2 N260 X-2 Z2 N270 X-3 Z3 N280 $ENDFOR N290 #HSC OFF N300 #OTC OFF (Deselect OTC) N310 #TRAFO OFF TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation...
-
Page 24: Figure 13Description Of Surf_Norm_Dir Function
Description #OTC [ SURF_NORM_DIR CONT/DISC/AUTO] Decoder BAVO CONT Covered distance Surface normal Offset Radius DISC Figure 13: Description of SURF_NORM_DIR function Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation... -
Page 25: Special Settings In Tool Data
If grinding_max_infeed is not set, no discrete offset can be applied. The following also applies: if grinding_wear_const is not set, it is not possible to calculate the con- tinuous offset depending on the path. TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation... -
Page 26: Connection To Plc
MC_CONTROL_SGN32_UNIT MCControlSGN32Unit Commanded, requested and return value ST element .command_w .D_Command .request_r .D_Request .state_r .D_State Data type DINT Unit 0.1 µm Value range [-P-TOOL-00031, P-TOOL-00031] Redirection ST element .enable_w .X_Enable Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation... - Page 27 MC_CONTROL_SGN32_UNIT MCControlSGN32Unit Commanded, requested and return value ST element .command_w .D_Command .request_r .D_Request .state_r .D_State Data type DINT Unit 0.1 µm Value range [-P-TOOL-00031, P-TOOL-00031] Redirection ST element .enable_w .X_Enable TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation...
-
Page 28: Axis-Specific Connection
MC_CONTROL_SGN32_UNIT MCControlSGN32Unit Commanded, requested and return value ST element .command_w .D_Command .request_r .D_Request .state_r .D_State Data type DINT Unit 0.1 µm Value range [-P-TOOL-00031, P-TOOL-00031] Redirection ST element .enable_w .X_Enable Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation... - Page 29 MC_CONTROL_SGN32_UNIT MCControlSGN32Unit Commanded, requested and return value ST element .command_w .D_Command .request_r .D_Request .state_r .D_State Data type DINT Unit 0.1 µm Value range [-P-TOOL-00031, P-TOOL-00031] Redirection ST element .enable_w .X_Enable TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation...
-
Page 30: Special V.g. Variables For Otc
Boolean type must be readable in the NC program. NOTE While OTC is active, V.G.WZ_AKT wear values are not up-to-date. They are only updated after OTC (#OTC OFF) is deselected. Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation... -
Page 31: Connecting To External Tool Management
If grinding_max_infeed is not set, no discrete offset can be applied. The following also applies: if grinding_wear_const is not set, it is not possible to calculate the con- tinuous offset depending on the path. TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation... -
Page 32: Parameter
P-TOOL-00032 Grinding disc tilt angle Description The parameter defines the angle between the centre line of the grinding disc and the 3rd main axis for tilted grinding discs. Parameter wz[i].grinding_disc_tilt_angle Version: 1.02 TF5200 | TwinCAT 3 CNC Online tool compensation... - Page 33 Parameter Data type REAL64 Data range -45°≤ grinding_tilt_angle ≤ 45° Dimension 0.0001° Default value Remarks Grinding disc tilt angle Also see about this 2 Special V.G. variables for OTC [} 30] TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation...
-
Page 34: Support And Service
Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet pages: https://www.beckhoff.com You will also find further documentation for Beckhoff components there. -
Page 35: Index
Index Index P-TOOL-00001 32 P-TOOL-00030 32 P-TOOL-00031 32 P-TOOL-00032 32 TF5200 | TwinCAT 3 CNC Version: 1.02 Online tool compensation... - Page 37 More information: www.beckhoff.com/TF5200 Beckhoff Automation GmbH & Co. KG Hülshorstweg 20 33415 Verl Germany Phone: +49 5246 9630 info@beckhoff.com www.beckhoff.com...
