Data I/O 298 Manual page 73

4. "ADDR" means that you can change the begin RAM
address by entering the hex value with the keyboard. If
an entry is not made, the value defaults to zero
(0),
If a
hex value appears in place of "ADDR," it is from a
previously entered RAM begin address.
If the default
Oi
pieviously entered vaiues are correct,
disrngard the
rz.zz.
characters in this step representing
the RAM address and enter only the terminal carriage
return (CR). If the values are incorrect, enter the data in
the sequence below:
298 Displays
( FR"il
l'iH"it
I
11\UU
ZZZZ(CR) or (CR)
P
r111
l'iH7f
.Ll\I
LIU
J
The terminal displays data in the following sequence:
COPY DATA FROM >
DEV ADDR,SIZE
>
CO DEV> RAM ADDR >
FAM HH PIN HH >
NOTE
If the Pak or programming module
installed does
not require a famiiy
I
pinout
code combination the 298 skips to the
display in step 5.
5. Enter the 4-digit hex family/pinout code combination for
the device to be copied. The codes are listed in the Pak
or programming module manual. If a code combination
appears on the display, it is from a previously entered
code.
If a previously entered family
I
pinout code is correct,
disregard the HHHH characters in this step representing
the family
I
pin out code and enter only the terminal
carriage return (CR). If the code is incorrect, enter the
correct code in the sequence below:
HHHH(CR) or (CR)
298 Displays
(LORTI
The terminal displays:
COPY DATA FROM >
DEV ADDR,S!ZE
>
CO DEV> RAM ADDR
>
FAM HH PIN HH >
LOAD DEVICE >
J
NOTE
If the pak installed has more than one
socket, the LED next to the correct
socket will illuminate.
6. Insert and lock the master device into the appropriate
socket. (See section 3.4.2i.
7.~E]
298 Displays
(' nRnr111h
L U
.lJ .L.
l'J '-'
TIE
11
rrE m)
.lJ-~ .LL - U
The terminal displays data in the following sequence:
COPY DATA FROM >
DEV ADDR,SIZE >
CO DEV> RAM ADDR. >
FAM HH PLN HH
>
LOAD DEVICE >
(Cursor Returns)
NOTE
The amount of time the programmer will
require to perform this ope;ation will vary
depending on the device size. The action
symbol line rotates 360 degrees while the
operation is taking place. When the
operation is complete the following
display signals the programmer's
readiness. If an error code is displayed,
see appendix E.
298 Displays
(LORIJ
nn111E
.lJ
Li"' -
HHHH)
The terminal displays data in the following sequence:
COPY DATA FROM >
DEV ADDR,SIZE >
CO DEV> RAM ADDR >
FAM HH PIN HH >
LOAD DEVICE
>
(Cursor Returns)
LOAD DONE HHHH
>
NOTE
HHHH is the hex sumcheck of the data
transferred, i.e., the hex sumcheck of
RAM data starting at the begin RAM
address and extending for a length of
address locations equal to the device size
minus the begin device address.
3-47
10-990-0013
