Inputting Remote Control Parameters - Data I/O 298 Manual

WHEN DEFAULT VALUES ARE ALL CORRECT:
DIRECT ENTRY
COvDEv TOvRA[CRJ
INTERACTIVE
CO[CRJ
!COPY DATA FROM> displayed on terminal)
DEICRI
(DEV ADDR,SIZE > displayed on terminal)
TOvRA(CRI
!CO DEV> RAM ADDA > displayed on terminal)
NOTE
The commands shown here are examples
only. The comp/ere list of commands is
in Table 3-6.
WHEN NO DEFAULT VALUES ARE CORRECT:
DIRECT ENTRY
COvDEvXXXX, VYYYv TOvRAvZZZZICRJ
INTERACTIVE
CO(CRI
!COPY DATA FROM> displayed on terminal)
DEICRJ
(DEV ADDA.SIZE> displayed on terminal)
XXXX, YYYYv TOvRA[CRJ
!COPY DEV> RAM ADDA> displayed on terminal)
ZZZZ(CRI
WHEN SOURCE ADDRESS DEFAULT IS CORRECT AND BLOCK
SIZE DEFAULT IS INCORRECT:
DIRECT ENTRY
COvDEV, XXXXv TOvRAICRI
INTERACTIVE
CO[CRl
!COPY DATA FROM> displayed on terminal)
DEICRJ
(DEV ADDR,SIZE > displayed on terminal)
,YYYYvTOvRA[CR]
(COPY DEV> RAM ADDA > displayed on terminal(CR]
Figure 3-5. Inputting Remote Control Parameters
COPY AND VERIFY COMMANDS. Use the following
procedures to perform the copy and verify procedures
using SRC.
Load RAM with Master Device Data. Use the following
procedure to load the 298 RAM with data from a master
device using a remote terminal and SRC:
to select the mode.
298 Displays
The terminal displays: COPY DATA FROM >
to select the source of the data.
298 Displays
[TIEii RTITIO
l~T'E
lJ
~
I\
lJ lJ
n
I
-J
.J. L.
TO)
The terminal displays the command and data in the
following sequence:
COPY DATA FROM>
DEV ADDR,SIZE >
3.
"ADDR" means that you can change the begin device
address to any address within the range of device word
limit by entering the hex value with the terminal. If an
entry is not made the value defaults to zero
(0).
If a hex
value appears in place of "ADDR" it is from a
previously entered begin address.
"SIZE" means that you can change the block size by
entering the hex value with the keyboard. If an entry is
not made the value defaults to device size. If a hex
value appears in place of "SIZE" it is from a previously
entered block size.
NOTE
If a begin address is specified then the
size must be specified also. The size
must be equal to or less than the device
size minus the begin address.
If the default or previously entered values are correct,
disregard the XXXX and/ or YYYY characters in this
step representing the device address and block size
respectively and enter only the terminal message
"TO(SP)RA(CR)." If the values are incorrect, enter the
data in the sequence below:
XXXX,
YYYY(SP)TO(SP)RA(CR)
or
TO(SP)RA(CR)
298 Displays
rn
'- '-'
The terminal displays:
COPY DATA FROM >
DEV ADDR,SIZE >
CO DEV> RAM ADDR >
3-46
10-990-0013
