a. If the hex value that appears in place of "SIZE" is
correct, go to step 4.
b. If it is incorrect, enter the correct hex value, then
go to step 4.
4.E?J
B
to select the destination for the data.
298 Displays
The prompt ( A ) preceding "ADDR" means that you
can change the begin device address by entering the
hex value with the keyboard. If an entry is not made,
the value defaults to zero (0). If a hex value appears in
place of "ADDR," it is from a previously entered
device begin address.
a. If the hex value that appears in place of "ADDR" is
correct, go to step 5.
b. If it is incorrect, enter the correct hex value, then
go to step 5.
NOTE
If the Pak or programming module
installed does not require a family I pinout
code combination the 298 automatically
skips the next step.
298 Displays
( F R "" ' " """"
I ll\UU
P r111
l.," ' " """'
uu
\
)
Enter the four digit hex family/pinout code
combination for the device to be programmed. The
codes are listed in the manual for the Pak or
programming module installed. If a code combination
other than zeroes appears on the display, it is from a
previously entered family and pinout code.
a. If the hex value that appears in place of the
family/pinout combination is correct, go to step 6.
6. Insert and lock the blank device into the appropriate
socket. (See subsection 3.4.2).
1.E?i
G
298 Displays
(TEST
TIEVICE
If the device passes the blank check and illegal bit test
the 298 automatically begins to program the device.
298 Displays
When the device has been successfully programmed
the 298 automatically verifies the programmed device.
298 Displays
(VERIF't ]EV ICE rJ)
NOTE
The amount of time the programmer will
require to perform these operations will
vary depending on the device size,
technology, and programming algorithm.
The action symbol character
[!]
rotates while
the operation is taking place.
8. When the operation is complete the following display
signals the programmer's readiness. If an error code is
displayed, see appendix E.
298 Displays
(PRG
Tin"'E
.LfUI"
I~
II
IL.I
f
NOTE
HHHHJ
b. If it is incorrect enter the correct family/pinout code
hex value, then go to step 6.
The number (01) following PRG DONE
(program done) is the sequence number.
The sequence number increments by 1
for each device programmed. HHHH is
the hex sumcheck of all the device data.
If block is defined, the sumcheck
(HHHH) will be calculated only for the
block size.
NOTE
If the Pak installed has more than one
socket, the LED next to the correct
socket will illuminate.
