4
·14
~
I~
RAM
JI
~
to se!ect the destination for the data.
29B Displays
(CO RRr1; RRr11\RIJIJR
J
2.
E?::1
The prompt ( /\ ) preceding "ADDR" means that you
can change the destination address by entering the hex
value with the keyboard. If an entry is not made, the
value defaults to zero (0). If a hex value appears in
place of "ADDR," it is from a previously entered
destination address.
a. If the hex value that appears in place of "ADDR" is
correct, go to step 5.
b. If it is incorrect, enter the correct hex value, then go
to step 5.
5.E?::i
298 Displays
B)
NOTE
The amount of time the programmer will
require to perform this operation will vary
depending on the block size. The action
symbol character
[!]
rotates while the
operation is taking place.
6. When the operation is complete the following display
signals the programmer's readiness. If an error code is
displayed, see appendix E.
(BLOC~' MO~'E
IJOrJE )
3.6.6 VERIFY RAM DATA AGAINST MASTER
DEVICE DATA
Use the following front panel keyboard procedure to verify
that the data in the 298 RAM is the same as the data in
the master device.
~
1 ·
I
I
to select the mode.
3-13
10-990-0013
to select the source of the data.
298 Displays
[ DRll;f
R
Tl TI r-1
I
c:
T
'E
f \ I I
I\
1 .lJ .lJ
r\
I
:J
.J. L. -
TO)
The prompt ( /\) preceding "ADDR" in the display
means that you can change the begin RAM address to
any address within the range of the RAM word limit
by entering the address hex value with the keyboard.
If an entry is not made, the value defaults to zero (0).
If a hex value appears in place of "ADDR," it is from
a previously entered begin address.
a. If the hex value that appears in place of "SIZE" is
correct, go to step 3.
b. If it is incorrect, enter the correct hex value, then
go to step 3.
298 Displays
The prompt ( /\) preceding "SIZE" means that you can
change the block size by entering the hex value with
the keyboard. If an entry is not made, the value
defaults to the device size. If a hex value appears in
place of "SIZE," it is from a previously entered block
size.
NOTE
If a begin device address is specified,
then the size must be specified also. The
size must be equal to or less than the
device size minus the begin device
address.
a. If the hex value that appears in place of "SIZE" is
correct, go to step 4.
b. If it is incorrect, enter the correct hex value, then
go to step 4.
