SmartLane

8. MAINTENANCE

ALL MAINTENANCE WORK ON THE EQUIPMENT MUST BE CARRIED OUT IN ACCORDANCE WITH THE REQUIREMENTS IN
THE SAFETY WARNINGS:  CHAP. 2, PAGE 8.
THE GROUND WIRES MUST INTERCONNECT ALL MOVING METALLIC PARTS (NOT BOLTED TO THE FRAME). SPECIAL
ATTENTION SHOULD BE PAID DURING DISASSEMBLY OF THESE ELEMENTS SO AS NOT TO DAMAGE THESE WIRES. IT IS
IMPERATIVE TO RECONNECT THEM DURING REASSEMBLY.

8.1. RECOMMENDED TOOLS

• Wrench or screwdriver TORX - N° 20 (T20, TX20, etc.) ;
• Electrician's toolkit: screwdrivers, pliers, etc. (For electrical connection);
• Mallet (to anchor the equipment to the floor);
• Ratchet wrench + extension + socket set;
• PC + mini USB or RJ45 Ethernet cable or supervision panel. (Optional) (To configure the lanes);
• Set of Allen keys;
• Flat spanner set.

8.2. RECOMMENDED TIGHTENING TORQUE

Recommended torque for tightening screws and nuts, unless otherwise specified:
Type of screw Torque (Nm)
M2 0.32
M3 1.15
M4 2.65
M5 5.2
M6 8.9
M7 14.5
M8 22
Type of screw
M10
M12
M14
M16
M18
M20
M22

Fig. 57 - Tightening torque

53
Torque (Nm)
43
75
119
182
250
355
480
