SmartLane

4.7.3. INTERMEDIATE UNIT

1
11
9
11
3 If mobile obstacle height ≥ 1200 mm

Fig. 9 - Location of the external components of the Standard SmartLane gate, intermediate

REF. DESIGNATION
1 Mobile obstacle
2 Fixed obstacle
3
3 Glass plate with dynamic status light/RFID logo
4 Front panel with dynamic orientation light
8 Right panel
9 Left panel
10 DIRAS detectors (Transmitter) behind a tinted screen
11 DIRAS detectors (Receiver) behind a tinted screen
12 Flap
2
10
12
3
4
9
10
8
19
12
3
4
8
