4.7.2. RIGHT UNIT

1
11
9
11
2 If mobile obstacle height ≥ 1200 mm

Fig. 8 - Location of the external components of the Standard SmartLane gate, right

REF. DESIGNATION
1 Mobile obstacle
2 Fixed obstacle
2
3 Glass plate with dynamic status light/RFID logo
4 Front panel with dynamic orientation light
5 Glass plate without dynamic status light / RFID logo
6 Front panel without dynamic orientation light
7 Rear panel
8 Right panel
9 Left panel
11 DIRAS detectors (Receiver) behind a tinted screen
12 Flap
2
12
3
4
7
8
18
SmartLane
5
6
