4.8.7. ASSY. LOGIC BOARD, INTERMEDIATE

13
16
12

Fig. 17 - Intermediate board

REF. DESIGNATION
12 AS1190 circuit board - Motherboard
13 AS1603 circuit board - Main and E/S interface board
14 AS1656 circuit board - Dynamic LED strip
15 AS1605 circuit board - Main and E/S interface board
16 4-Pole through base
26
SmartLane
14
15
