4.4. RANGE

The SmartLane gates control the access of pedestrians with or without luggage, in both directions, guaranteeing high levels
of security and safety.
They are available in two (2) widths of passage (lane), according to the width of the obstacle, as shown in the table below:
Standard SmartLane
Standard obstacle
Passage width of 600 mm
Passage for users
with ordinary mobility
Wide SmartLane
Wide obstacle
Passage width of 900 mm
Passage for users
with reduced mobility
* Option
The gates can of course be installed singly or in a group. In the latter case, the conventional direction being A, a left-hand gate
(1), a right-hand gate (6) and intermediate gates (2, 3, 4 and 5) will be defined, with the possibility of the latter being hybrid
(3 and 5): i.e. linking two lanes of different widths.
1 2
B
A
Without extension
Without extension
3
B B
A A

Fig. 3 - Example of SmartLane products

1 extension *
1 extension *
4
B
A
