Figure 3-18
3.5

Connecting Cables

Connect a twisted-pair cable to the LAN port of the AP. For details about the twisted-pair
cable connection sequence supported by the AP, see
Caution
By default, the baud rate is set to 9600, data bit to 8, stop bit to 1, with no parity check
and no flow control on the console port of the AP. The console port is used only when you
want to configure the AP manually.
3.6

Bundling Cables

3.6.1

Precautions

Bundle the power cords and other cables in a visually pleasing way.

Bend twisted pairs naturally or to a large radius close to the connector.

Do not over tighten twisted pair bundle as it may reduce the cable life and

Disassembling the AP
7.1 Connectors and
29
Installation
Media.
