Hardware Installation and Reference Guide
Note:
When installing or moving the wireless AP, ensure that the power supply is cut off.

Ensure that the screws are tightened.

Ensure that the AP is installed at a site where the LED can be easily observed.

3.4.2

Removing the AP

(1) Use a flathead screwdriver to remove the cover from the AP. Slightly pry up the cover
at the openings at both sides of the AP.
Figure 3-7 Removing the Cover
(2) Loose the screws on the AP to remove the AP from the junction box.
3.5

Connecting Cables

Connect twisted pairs to the WAN/PoE port on the AP. See
for supported wiring of twisted pairs.
Caution
By default, the baud rate is set to 9600, data bit to 8, stop bit to 1, with no parity check
and no traffic control on the console port of the AP. The console port is used only when
you want to configure the AP manually.
7.1
21
Installing the Access Point
Connectors and Media
