Radio Specifications
Modulation Modes
Receiver Sensitivity
1.4.3

Port Specifications

Table 1-6 Port Specifications
Port
Fixed Service Ports
Fixed Management
Ports
RG-MAP852-SF-U
IEEE 802.11b: BPSK, QPSK, CCK
IEEE 802.11a/g/n: BPSK, QPSK, 16-QAM, and 64-QAM
IEEE 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, and 256-QAM
IEEE 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM,
1024-QAM
IEEE 802.11b: –96 dBm (1 Mbps), –93 dBm (5 Mbps), –89 dBm
(11 Mbps)
IEEE 802.11a/g: –91 dBm (6 Mbps), –85 dBm (24 Mbps), –80
dBm (36 Mbps), –74 dBm (54 Mbps)
IEEE 802.11n: –90 dBm @ MCS0, –70 dBm @ MCS7, –89 dBm @
MCS8, –68 dBm @ MCS15
IEEE 802.11ac: HT20: –88 dBm (MCS0), –63 dBm (MCS9)
IEEE 802.11ac: HT40: –85 dBm (MCS0), –60 dBm (MCS9)
IEEE 802.11ac: HT80: –82 dBm (MCS0), –57 dBm (MCS9)
IEEE 802.11ax: HE80: –82 dBm (MCS0), –57 dBm (MCS9), –52
dBm (MCS11)
IEEE 802.11ax: HE160: –78 dBm (MCS0), –53 dBm (MCS9), –48
dBm (MCS11)
RG-MAP852-SF-U
Uplink: 1 × 2.5G SFP port, not conformity to 1G SFP ports
Downlink: 8 × 10/100/1000Base-T adaptive Ethernet electrical
ports
1 × Micro USB console port
8
