Hardware Installation Guide
1.4.2

Radio Specifications

Table 1-5 Radio Specifications
Radio Specifications
Radio Design
Operating Band
Transmission Rate
Antenna Type
Antenna Gain
Maximum Transmit
Power
Power Adjustment Step 1 dBm
RG-MAP852-SF-U
Dual radios
The system supports four spatial streams.
Radio 1 (first channel): 2.4 GHz, 2 spatial streams: 2 × 2,
MU-MIMO
Radio 2 (second channel): 5 GHz, 2 spatial streams: 2 × 2,
MU-MIMO
Radio 1:
IEEE 802.11b/g/n/ax, 2.400–2.4835 GHz
Radio 2:
IEEE 802.11a/n/ac/ax, 5.150–5.350 GHz, 5.470–5.725 GHz
IEEE 802.11a/n/ac/ax, 5.725–5.850 GHz
Note: The operating band varies in different countries.
Radio 1: 2.4 GHz, 574 Mbps
Radio 2: 5 GHz, 2.402 Gbps
Maximum access rate of the AP
2.4 GHz+5 GHz, 2.976 Gbps
Built-in omnidirectional antenna
2.4 GHz: 3 dBi
5 GHz: 3 dBi
20 dBm
Note: The transmit power varies based on the regulations in
different countries and regions.
