Hardware Installation and Reference Guide
Introduction
Table 1-10
LED Color
N/A
Green
Green
Green
1.6

Optical Module

The type of the port on the device directly connected with the 10G SFP port on the AP can
be an optical port or electrical port. However, the negotiated rate varies depending on
the port rate or optical module used on both devices. For details, see Table 1-11 and
Table 1-12.
Press and hold the
button for longer
than 5s
Bridge LED
No. of
Steady-on
Description
LED
The AP does not enable the bridge function.
N/A
The AP has enabled the bridge function, but bridging fails.
Bridging is successful, and the strength of the wireless
1
signals dedicated for bridging is less than –70 dBm.
Bridging is successful, and the strength of the wireless
1, 2
signals dedicated for bridging ranges from –70 dBm to –50
dBm.
Bridging is successful, and the strength of the wireless
1, 2, 3
signals dedicated for bridging is greater than –50 dBm.
Restore to factory settings.
14
