Power Supply and Consumption

Table 1-7 Power Supply and Consumption
Power Supply and
Consumption
Power Type
Power Supply to
External Devices
Maximum Power
Consumption
Power Supply
Redundancy
Caution
 To power the AP by using PoE, ensure that the device at the other end of the Ethernet
cable supports IEEE 802.3af power supply.
 In 802.3af power supply state, the device can be started properly. All RF cards do not
work, and the PSE does not power external devices.
 In 802.3at power supply state, radio 3 does not work, and the PSE does not power
external devices.
 In 802.3bt power supply or AC power supply state, the device has the highest
performance and all functions are enabled.
One system status LED
Three RSSI LEDs
One reset button
RG-AP680-AR
1. 100–240 V AC power supply (equipped with the RG-PL-M16-3M
cable, and 1 A current must be guaranteed)
2. PoE/PoE+/PoE++ (IEEE 802.3af/at/bt-compliant)
Supported (Connect to Ruijie IoT module, 802.3af-compliant,
support for 15.4 W output power)
≤ 50 W
Not supported
