Hardware Installation and Reference Guide
Figure 3-4
Installing the Mounting Bracket
(2) Assemble the mounting bracket flange and installation pole and use two M6 hex
socket combined screws to fix the left and right sides.
Note
The mounting bracket flange and installation pole can be assembled in vertical or
horizontal mode based on the actual coverage requirements.
26
Installation
