Hardware Installation and Reference Guide
Introduction
Figure 1-5 LED Status
Status
Off
Steady green
Steady red
Blinking red at
an interval of 1s
Blinking blue at
an interval of
0.2s
Steady blue
Blinking blue at
an interval of 1s
Blinking red at
an interval of
0.2s
Table 1-9 Reset button
Button
Reset button
Frequency
N/A
N/A
N/A
On for 3s
Off for 1s
On for 0.2s
Off for 0.2s
N/A
On for 1s
Off for 1s
On for 0.2s
Off for 0.2s
Operation
Press the button for
less than 2s
Description
The AP is not powered on.
The AP is powered on, but the LED is manually
turned off.
The software system of the AP is being
initialized.
The system is running properly, but the uplink
service port is linked down.
In fit mode, the setup of a CAPWAP tunnel
between the AP and AC timed out.
In fit or MACC mode, the software system of
the AP is being updated.
The system is running properly, but there is
no STA online.
The system is running properly and there are
one or more STAs online.
In fit mode, the AP is being located.
Result
Reboot the device.
13
