BASIC OPERATION

■ Selecting a Channel oo Group
D Using the channel and gooup selectoo
1. Push [CH/GRP] to toggle the Channel Select
mode or the Group Select mode.
• " " or " " is displayed.
2. Rotate [CH/GRP] to select a channel or group.
Example
When selecting the Group Select mode, the User
channels change in 20 channel steps.
NOTE: See the Channel and Channel Group list
below.

D Using the keypad

• When selecting a Useo channel
1. Push the keypad keys to enter the channel
number.
2. Push [ENT] to set.
Example
• Selecting CH 41: [4
• Selecting CH 128: [1] → [2
• When selecting an ITU duplex channel
1. Push the keypad keys to enter the channel
number.
2. Push [ENT] to set.
Example
• Selecting CH 401: [4
• Selecting CH 2505: [2
[5
NOTE:
• See the Channel and Channel Group list below.
• Pushing [CLR] clears the entered digits and return to the
previous channel.
• Channel and Channel Group list
Channel No. Descoiption
1 ~ 160 User CH*
401 ~ 429 4 MHz ITU duplex CH
4-1 ~ 4-9 4 MHz ITU simplex CH
601 ~ 608 6 MHz ITU duplex CH
6-1 ~ 6-9 6 MHz ITU simplex CH
801 ~ 837 8 MHz ITU duplex CH
8-1 ~ 8-9 8 MHz ITU simplex CH
11
] → [1] → [ENT]
ghi
] → [8 ] → [ENT]
abc tuv
] → [0] →[1]→ [ENT]
ghi
] → [5 ] →[0] →
abc Jkl
] → [ENT]
Jkl
Channel No.
1201 ~ 1241
12-1 ~ 12-9
1601 ~ 1656
16-1 ~ 16-9
1801 ~ 1815
18-1 ~ 18-9
2201 ~ 2253
• Channel Select mode
• When selecting an ITU simplex channel
1. Push the keypad keys to select a frequency band.
2. Push the left most Software Key to enter "– "
(dash).
Selected frequency band is
briefl y displayed.
Push
3. Push the keypad keys to enter the channel
number.
4. Push [ENT] to set.
Example
• Selecting CH 4-1: [4
• Selecting CH 25-2: [2
Descoiption Channel No.
12 MHz ITU duplex CH 22-1 ~ 22-9
12 MHz ITU simplex CH 2501 ~ 2510
16 MHz ITU duplex CH 25-1 ~ 25-9
16 MHz ITU simplex CH C1-1 ~ C1-21
18 MHz ITU duplex CH C2-1 ~ C2-31
18 MHz ITU simplex CH
22 MHz ITU duplex CH
[ENT]
[CH/GRP] [CH/GRP]
[CLR] [CLR]
• Group Select mode
] → →[1]→ [ENT]
ghi
] → [5 ] → →
abc Jkl
[2 ] → [ENT]
abc
Descoiption
22 MHz ITU simplex CH
25 MHz ITU duplex CH
25 MHz ITU simplex CH
C1 channels
C2 channels
* [GRP] changes in 20 channel steps.
