Caution:
The library's internal components are static-sensitive devices. Please
use a static dissipative wrist strap or other ESD equipment and tools
for this process.
Use the appropriate scewdriver to loosen or remove the three library cover
1.
screws on the rear of the library (Figure 4).
Š
Screws that require a Phillips screwdriver cannot be totally removed from the
cover. Loosen the screws sufficiently to fully disengage the cover.
Š
Screws that require a flat head screwdriver must be completely removed frm
the cover.
Slide the cover toward the rear of the library (Figure 5) about one-half inch. This
2.
will release the side clips holding the cover to the faceplate.
Remove the cover by lifting it straight up, and set it aside (Figure 6).
3.
Figure 5 Slide cover back.

Remove the Cover

Figure 4 Remove the library cover screws.
Figure 6 Lift cover.
Spectra 10000 Library AIT Tape Drive Installation Guide 13
