Record the Library Configuration

Access the Main screen on the library's LCD display. This screen has the Spectra 10000
button in the upper left corner (Figure 2).
Touch the Spectra 10000 button to access the Spectra 10000 screen (Figure 2).
1.
Figure 2 Main screen to Spectra 10000 screen.
In the table below, record the SCSI IDs for the drives and the library, as well as
2.
the library configuration switch setting. This is a precautionary measure in the
event that switch settings are inadvertently changed.
In a library configured with a Fibre Channel interface, the device SCSI IDs are
hard-coded and cannot be changed.
Device
Drive 1
Drive 2
Drive 3
Drive 4
Library/SCSI ID
Library configuration switch
Note:
The Spectra 10000 library can have two independent SCSI busses. For
more complete information on configuring dual SCSI busses, refer to
Chapter 3 in the Spectra 10000 User Guide.
6 Spectra 10000 Library AIT Tape Drive Installation Guide
This Example Your Library
(Figure 2)
15
8
7
6
0,1
0
