Product Overview 7
Typical Coverage

1.7.2 Typical Warehouse Paging Setup

Figure 1-4. Typical Warehouse Paging Setup
Loud Speaker Amplifier
"High Power Mode" with
Loud Speaker Amplifier
Two (2) Horn Speakers Attached
Part Numbers: 011404 and 011405 Part Number: 011405
Horn Speaker Horn Speaker Horn Speaker Horn Speaker Horn Speaker Horn Speaker
Horn to Loud Speaker Amplifier
Horn Speaker to Horn Speaker
25' 25'
50'
Office Bathroom
Typical Example of a 70,000 Square Feet Warehouse Paging Set up
Operations Guide 931976A CyberData Corporation
