1.7.2 Typical Warehouse Paging Setup
Loud Speaker Amplifier
Part Numbers: 011404 and 011405
Horn Speaker
Operations Guide
Figure 1-4. Typical Warehouse Paging Setup
Horn Speaker
Horn to Loud Speaker Amplifier
25'
25'
Typical Example of a 70,000 Square Feet Warehouse Paging Set up
"High Power Mode" with
Two (2) Horn Speakers Attached
Horn Speaker
Horn Speaker
Horn Speaker to Horn Speaker
931281I
Loud Speaker Amplifier
Horn Speaker
50'
CyberData Corporation
Horn Speaker
Office
Bathroom
