Installing the InformaCast Enabled Paging Amplifier
19
InformaCast Enabled Paging Amplifier Setup
Figure 2-15. Connecting the 011288 Auxiliary RGB (Multi-Color) Strobe Kit
Outdoor Loudspeaker Amplifier with IP66 Rating Enclosure
Cable Exit
Cable Exit
to
J1
J1
to
JX
Indoor Auxiliary RGB Strobe
Lock
Washer
Speaker / PA / Intercom
to Strobe Cable
Speaker / PA / Intercom to Strobe Cable
Remove Cord Grip Assembly
then Replace with
Network Cable
1/2" EMT Compression Connector
Operations Guide
931976A
CyberData Corporation
