2.3.8.1 Point-to-Point Configuration
When the device is set to not register with a SIP server (see
speaker to receive Point-to-Point calls by setting the dial out extension to the IP address of the
remote device. The delayed DTMF functionality is available in Point-to-Point Mode.
Note
CyberData InformaCast SIP
Device is set to NOT register with a SiP server
2.3.8.2 Delayed DTMF
On the SIP Configuration page the dial out extension supports the addition of comma delimited
pauses and sending additional DTMF tones (using rfc2833). The first comma will pause three
seconds after a call is first established with a remote device. Subsequent commas will pause for 2
seconds. A pause of one second will be sent after each numerical digit.
Extension String
302
302,2
302,25,,,4,,1
Note
Operations Guide
Receiving point-to-point SiP calls may not work with all phones.
Figure 2-29. SIP Page Set to Point-to-Point Mode
Paging Amp
Table 2-14. Examples of Dial-Out Extension Strings
Resulting Action
Dial out extension 302 and establish a call
Dial out extension 302 and establish a call, wait 3 seconds then send the
DTMF tone '2'
Dial out extension 302 and establish a call, wait 3 seconds then send the
DTMF tone '2', send out DTMF tone 5, wait 6 seconds, send out DTMF
tone 4, wait 4 seconds, send out DTMF tone 1
The maximum number of total characters in the dial-out field is 25.
931976A
Installing the InformaCast Enabled Paging Amplifier
InformaCast Enabled Paging Amplifier Setup
Figure 2-29), it is possible for the
