HCR 102 Reset Mode Summary — Front Panel-Based Resets
Use This Activation
Mode to...
Toggle stop/start To stop or start a program:
program
1. Hold down the Reset button for about 3 seconds,
until the Power LED blinks once.
2. Release and press the Reset button momentarily
(for <1 second) within 1 second*.
* Nothing happens if the momentary press does not
occur within 1 second.
Enable or To enable or disable the DHCP client for the LAN port:
disable the
1. Press the Reset button five times (consecutively).
DHCP client
2. Release the button. Do not press the button within
3 seconds following the fifth press.
NOTES:
The DHCP toggle mode is supported on
•
firmware version 1.01 or higher.
By default DHCP is off and the unit uses a static
•
IP address.
Reset IP settings To reset all IP settings:
and port maps
1. Hold down the Reset button for about 6 seconds
to factory
until the Power LED blinks twice (once at 3 seconds,
defaults without
again at 6 seconds).
affecting user-
2. Release and press the Reset button momentarily
loaded files
(for <1 second) within 1 second*.
* Nothing happens if the momentary press does not
occur within 1 second.
Start over with To reset the unit to all factory default settings via front
configuration panel:
and uploading
1. Hold down the Reset button for about 9 seconds
until the Power LED blinks three times (once at 3
seconds, again at 6 seconds, again at 9 seconds).
2. Release and press the Reset button momentarily
(for <1 second) within 1 second*.
* Nothing happens if the momentary press does not
occur within 1 second.
NOTE: The factory configured password for this
device has been set to the device serial number.
Passwords are case sensitive. Performing a
Reset to Factory Defaults reset sets the password
to extron.
NOTE: After performing a Reset All IP Settings or Reset to Factory Defaults reset, set the IP address again (by
using the OSD menu, Toolbelt, or PCS) for use on your network.
Result
The LED flashes 2 times if the program is starting.
The LED flashes 3 times if the program is
stopping.
NOTE: This mode is available only via front
panel.
The Reset LED blinks 6 times if the DHCP
•
client is enabled.
The Reset LED blinks 3 times if the DHCP
•
client is disabled.
NOTE: When you disable the DHCP client,
the unit reverts to using the previously-set
static IP address.
Reset All IP Settings mode:
Sets the LAN IP address back to factory
•
default (192.168.254.250)
Sets the subnet back to factory default
•
(255.255.255.0)
Sets the default gateway address to the
•
factory default (0.0.0.0)
Sets domain and host names to factory default
•
Sets port mapping back to factory default
•
Turns DHCP off
•
Turns events (user-created schedules, macros)
•
off.
NOTE: This mode is available only via front
panel.
Reset to Factory Defaults mode performs a
complete reset to factory defaults (except
the firmware).
Resets all AV settings.
•
Does everything Reset All IP Settings mode
•
does
Removes (clears) all user-loaded files and
•
configurations from the HCR 102:
Clears driver-port associations (IR, serial,
•
Ethernet) and port configurations
Removes schedules, settings, macros
•
Removes user-loaded digital certificates.
•
Removes the factory default GC configuration.
•
The basic GC configuration project can be
downloaded from the Extron website if you
want to restore it to the unit after a reset.
NOTE: This mode is available via front
panel, Toolbelt, and PCS.
The preferred methods for starting this
reset are front panel and Toolbelt.
In PCS this mode is called "Reset All
Settings and Delete Files."
This is also known as an absolute
system reset.
