4. Start Device Discovery (click Start Discovery or Discovery, depending on the
Toolbelt version). Toolbelt searches for and displays a list of all Extron control devices
connected to the network as it detects them.
NOTE: If your device does not appear in the Discovery list, navigate to the menu
and select Tools > Options.... An Options dialog box opens. Verify that
the selected network interface is either All or the specific network interface that
connects to the LAN used by the HCR. Close the dialog box.
5. Using the MAC address, locate the desired device (HCR 102) in the list and select it.
6. Choose one of the following options (see the rightmost column of the device list):
Click the Set IP link or icon (if available). A Set Network Properties dialog
•
box opens.
a. Configure the IP address, subnet mask, and gateway address as needed.
b. Click Enter. The system saves the settings and closes the dialog box.
Click the Manage link and then click the Network Settings tab in the right side
•
of the window.
a. Either select (enable) the Use DHCP checkbox to have the receiver obtain an IP
address automatically from a DHCP server, or enter the static IP address for the
unit in the IP Address field.
NOTE: When setting up DHCP during network configuration or if using a
host name instead of an IP address, the user must enter a qualified host
name (Username.Hostname.Domain). For example:
somename.extron.com.
b. Configure the other items (device or host name, subnet mask, gateway
address, DNS server address) as needed.
c. Click Apply to save the configuration changes or click Cancel to discard
changes.
