… Write down the MAC address of each HCR 102 (see
location) or other IP Link Pro device to be used.
… Obtain model names and setup information for devices the HCR 102 will control.
Step 2 — Mount the Receiver and HCT 103, Prepare the Installation Site for
Other Transmitters
… Mount the HCT 103 (if applicable) and HCR 102 to furniture, a wall (see
HCT 103 and HCR 102
… Prepare the site (install a junction box or mud ring in furniture or a wall) for the
HCT 102 D, or prepare an optional rack mounting kit for it. Do not mount the unit into
the wall or furniture, however, until cabling and testing are completed.
…
Prepare the site (install a junction box in furniture or a wall) for the HCT 101 EU or
HCT 101 MK. Do not mount the unit into the wall or furniture, however, until cabling and
testing are completed.
… Cable and mount any optional TLP Pro touchpanels or NBP button panels as needed
(see the user guide for the TLP or the NBP Series User Guide for details).
Step 3 — Cable All Devices
…
Ground the HCT 101 EU or HCT 101 MK transmitter (see
…
Cable devices to the transmitter and receiver (see
Connections
1. Connect AV sources to the input connectors (see
page 18).
2. Use a shielded twisted pair cable to connect the transmitter to the receiver via the
output and input RJ-45 connectors (see
on page 19).
3. Connect AV output devices (display, projector, or other device, and an amplifier
or powered speakers) to the output connectors (see
page 20).
4. If applicable, use Extron Show Me cables or connect a remote keypad to the
Remote ports on the transmitter for controlling and indicating input selection (see
Transmitter connections for input selection and indication
5. Cable the control ports on the receiver as desired for controlling AV devices and for
communicating with the system via LAN (see
Step 4 — Connect Power
…
Connect power cords (see
the devices.
NOTE: The power supplies can be set on a tabletop, or mounted to a rack or
furniture. Follow the mounting directions included with each power supply or see
the power supply installation guides available on the
page
on page 71) or a rack, or set them on a table top.
starting on page 16).
Power input connector
on the Extron website.
HC 400 Series • Hardware Features and Installation
figure 7, O on page 16 for
Mounting the
Grounding on page 34).
Rear and Side Panel Features and
AV Input Cabling
Transmitter-Receiver Interconnection
AV Output Cabling
on page 21).
Control Cabling on page 21).
on page 32) and power on all
PS Series Power Supplies
on
on
