Transmitters

Transmitter
Model
HCT 103
HCT 102 D
HCT 101 D
HCT 101 EU
HCT 101 MK
For any of these transmitters, if the selected input is HDMI, the extended video signal can
be HDCP-compliant.

Receiver

The HCR 102 receiver incorporates a high performance, HDCP compliant scaler that scales
video to provide a consistent output resolution to a display. It accepts video with resolutions
from 480i up to 1920x1200, 1080p, and 2K, and performs upscaling and downscaling with
multiple output rates up to 1920x1200, including HDTV 1080p/60 and 2K. The receiver
includes an on-screen display, test patterns, and EDID Minder.
Analog Digital
Video HDMI Video
Inputs Inputs
1 2
1 1
0 1
0 1
0 1
Features
Analog Input Input
Audio Selection Selection
Inputs Buttons LEDs
1 Yes
2 No
1 No
0 No
0 No
HC 400 Series • Introduction
Mounting
Type
Yes Rack mount
(1 inch high,
half rack wide)
Yes 2-gang US,
decorator-style
No 1-gang US,
decorator-style
No 1-gang EU,
55 mm
No 1-gang MK,
55 mm
3
